The Bosch Rexroth Indramat DDS03.2-W015-BE56-01-FW from the DDS Drive Controllers series is a high-performance modular servo controller engineered for industrial motion applications. It features an internal cooling system designed for heat dissipation within control cabinets and supports a rated current of 15 A for continuous operation. Feedback versatility is provided through digital servo feedback and resolver feedback, guaranteeing precise motor control across variable loads. Compatibility extends to Bosch Rexroth ADP inductance motors, 2AD inductance motors, and MKS synchronous motor families.
The controller receives its supply from any Bosch Rexroth regulated 24 V DC unit and houses a dedicated software module and command communication module that store firmware and operating parameters on an identifiable type plate. Command and feedback exchange runs over SERCOS, leveraging fiber-optic links in a ring topology to ensure redundancy and deterministic high-speed communication. The unit’s basic framework accommodates plug-in modules to expand functionality, while firmware versions remain traceable via the hardware configuration type plate.
Engineered for ambient temperatures up to 45 °C, the DDS03.2-W015-BE56-01-FW maintains stable operation within standard control cabinet environments. Its modular design, comprehensive feedback support, and robust communication protocol make it ideal for robotics, printing, handling machines, and textile automation where reliability and precision are critical.
Cooling
Internal Cooling
Motor Feedback
Digital Servo and Resolver Feedback
Rated Current
15 A
