The Indramat MPN R911262672 (DDS02.1-W025-DS11-01) is a drive controller from the DDS02 series, featuring a modular configuration for digital intelligent AC servo and main drives using a unified supply unit. It functions with a DC bus voltage of 300 V ±15% and requires a regulated 24 V DC connection. The controller includes internal cooling for heat dissipation within the housing and provides IP10 protection against solid objects larger than 50 mm. Interaction with motors is achieved via digital servo feedback, and a SERCOS interface module enables integration with compatible controls through fibre optic connection. The rated current is 25 A. Operational conditions are 0°C to 40°C, altitudes up to 1000 m, and relative humidity up to 95%.

Technical Specifications

Product Type
Drive Controller

DC Bus Voltage
300V +/- 15%

Supply Voltage
24V with regulated DC

Cooling Method
Heat technology

Ingress Protection Rating
IP 10

Motor Compatibility
Motors with Digital Servo Feedback

Interface
SERCOS interface with fibre optic cable

Function ID
11

Version ID
01

Operating Temperature
0oC to 40oC

Installation Altitude
maximum of 1000m above sea level

Relative Air Humidity
maximum of 95%
