R911263129 (DDS02.1-W200-R)

DDS Drive Controllers

In Stock, Ships 2-3 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth R911263129 (MPN: DDS02.1-W200-R) is a drive controller designed for precision servo motor control in industrial automation systems. This model supports a constant current of 65 A and a peak current of 200 A, and is housed within an air control cabinet rated at IP 10, featuring internal cooling to maintain operational stability at ambient temperatures from 0 to 45 degrees Celsius. It utilizes resolver feedback for accurate motor speed and position control. System parameters can be transferred via software module replacement. Reference to the appropriate user manual is required for safe and correct operation.

Technical Specifications

Constant Current
65 amps

Weight
7.5 kg

Control Cabinet Rating
IP 10

Air Conditioning System
Outside Air Intake, Exhaust Heat Outside Cabinet

Heat Regulation
Yes

Main Function
Precision Control of Servo Motors

Power Dissipation
560 W (at 90 A current)

Operating Temperature Range
0-45 degrees Celsius

Max Allowed Temperature (Derated Data)
55 degrees Celsius

Peak Current
200 A

Feedback System
Resolver Feedback

Assembly and Operating Height
Up to 1000 meters

Firmware
Separately Available

Replacement
Possibility with Software Module
