R911265149 (DDS02.1-A100-SK01-00)

DDS Drive Controllers

In Stock, Ships 2-3 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth MPN R911265149 (DDS02.1-A100-SK01-00) is a drive controller designed for use with synchronous, linear, and frameless motors within the DIAX04 drive system. It operates with a DC input voltage of 300V applied at L- and L+ terminals and provides current output at A1, A2, and A3 terminals. Featuring a rated continuous current of 100 A and supporting digital servo feedback for motor control, the unit utilizes an external air cooling system. It is classified under IP10 and intended for cabinet installation with at least IP54 protection and sufficient airflow. The device features five configurable plug-in slots, a firmware module in the U5 slot, an RS232 interface, and operates within 0–45°C up to 1000 meters altitude, with a maximum power consumption of 500 mA at +24VDC.

Technical Specifications

Type
Drive Controller

Drive System
DIAX04

Input Voltage
300 VDC

Rated Current
100 A

Cooling System
Air cooled

Protection Category
IP10

Number of Slots
5

Firmware Slot
U5

Ambient Temperature Range
0 to +45 degree Celsius

Maximum Altitude
1000 meters

Interface
RS232

Power Consumption at +24VDC
500 mA
