R911265886 (DDS02.1-F200-DA02-00)

DDS Drive Controllers

In Stock, Ships 2-3 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

4 Minutes 10 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The Indramat MPN R911265886 (DDS02.1-F200-DA02-00) is a drive controller engineered for the operation of MDD, MKD, and LAR motors. It requires a 24 VDC regulated power supply and provides a continuous output current of 200 A. The unit features a digital servo feedback system and supports communication through an analog interface. The controller is housed in an IP10 enclosure, offering protection from solid objects over 50 mm in diameter. Installation should follow vertical mounting with designated spacing in environments between 0°C and 45°C and up to 1000 m elevation. The device measures 390 x 105 x 325 mm, uses M6 mounting screws, weighs 11 kg, and employs coolant technology for thermal management.

Technical Specifications

Compatible Motors
MDD, MKD, LAR

Input Power
DC

Input Volatge
24 Volts DC

Output Current
200 Amps

Function ID
02

Function Version
00

Protection Rating
IP10

Ambient Operation Temprature
0-45 degrees Celsius

Maximum Operation Elevation
1000 meters

Communication Interface
Analog

Feedback Interface
Digital servo feedback

Orientation
Vertical

Dimensions
390 x 105 x 325 millimeters

Mounting Clearance Above
80 millimeters

Mounting Clearance Below
80 millimeters

Mounting Clearance Front
40 millimeters

Mounting Clearance Back
25 millimeters

Mounting Screw Size
M6

Maximum Tightening Torque
5 Nm

Weight
11 Kilograms
