The R911266446 (DDS02.2-W100-BE32-01-FW) is an AC servo control drive from the Rexroth Indramat DDS series. This digitally operated, modular drive features internally air-cooled construction suitable for installation in a control cabinet. It supports motor feedback via both digital servo and resolver systems, and delivers a rated output current of 100 A. Operating parameters include an ambient temperature range of 0°C to +45°C at rated output, up to +55°C with de-rating, and storage or transportation capability between -30°C and +85°C. With a maximum relative humidity tolerance of 95% (absolute up to 25g/m³) and functional up to 1000 meters altitude, the unit is classified as IP20 according to EN 60529.

Technical Specifications

Product Type
Modular and digital AC servo control drive

Version
2

Motor Feedback
Digital, factory-assigned

Rated Current
100A

Maximum Ambient Temperature with Derated Data
+550C

Permissible Ambient Temperature with Rated Data
0 to +450C

Transportation or Storage Ambient Temperature
-300C to +850C

Maximum Permissible Relative Humidity
95%

Maximum Allowable Absolute Humidity
25g/m3

Maximum Installation Elevation with Rated Data
1000 meters

Protection Category
IP20 EN 60529 = DIN VDE 0470-1-1992 (IEC 529-1989)
