R911270585 (DDS02.1-W200-DA14-01-FW)

DDS Drive Controllers

Rated 5 stars (14 total reviews)

In Stock, Ships 2-3 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

3 Minutes 26 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The R911270585 (DDS02.1-W200-DA14-01-FW) is a drive controller from Bosch Rexroth engineered for industrial automation applications, including printing, textiles, and packaging. It is compatible with LAR, MKD, and MDD motors and utilizes integrated resolver feedback to enable precise control of speed, position, and torque. The unit employs internal air circulation for heat dissipation and requires installation in a control cabinet. Rated for operation at altitudes up to 1000m and ambient temperatures from 5°C to 45°C, it has an ingress protection rating of IP20. The modular architecture allows for individual firmware modules, which contain drive parameters, to be interchanged as needed. The device supports a rated current of 200A.

Technical Specifications

Product Type
Drive Controller

Compatible with
LAR, MKD, MDD motors

Feedback Mechanism
Resolver feedback

Cooling Mechanism
Heat technology

Operational Elevation
Up to 1000 m above sea level

Modular Structure
Yes

Firmware
Can be pre-configured and updated

Operating Temperature Range
5C to 45C

Ingress Protection Standard
IP 20

Shipping
Available worldwide
