R911280372 (DDS02.2-W015-BE84-01-FW)

DDS Drive Controllers

In Stock, Ships 2-3 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth R911280372 (DDS02.2-W015-BE84-01-FW) is a drive controller engineered for integration with Rexroth Indramat supply units. Its hardware supports resolver and digital servo feedback, with a rated and peak output current of 15 A, and its EMC-compliant design features internal cooling. The unit provides a SERCOS interface communication module and includes five available slots for plugin, command communications, and software modules to facilitate system customization. Operating parameters specify a DC bus voltage of 300V, power dissipation of 110 W at 15 A continuous current, and an ambient temperature range from 0 to +45 °C. Firmware must be sourced separately in line with application requirements.

Technical Specifications

Product
Bosch Rexroth Drive Controller

Feedback
Resolver and Digital Servo

Weight
7.5 kg

Firmware
Not included, must be purchased separately

Current
Continuous and Peak of 15 A

Place of Operation
With Rexroth Indramat supply units

Extra Module Slots
Five slots, U1-U5

Communication
SERCOS Interface Communication Module

Operating Temperature
0 to +45 degrees Celsius

DC Bus Voltage
300 volts

Power Dissipation
110 Watts at 15 A Continuous Current

EMC Compatibility
Yes

Pre-shipment Testing
Yes
