R911283011 (DDS02.2-W015-BT27-01-FW)

DDS Drive Controllers

In Stock, Ships 2-3 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth drive controller with MPN R911283011 (DDS02.2-W015-BT27-01-FW) is specified for use with motors featuring digital servo and resolver feedback. It employs internal cooling technology and supports a rated current of 15 A. Operation must remain within a maximum ambient temperature of 55°C. The unit consumes 500 mA at 24 VDC and requires a constant earth wire connection. Connectors A1, A2, and A3 are designed for M6 screws torqued to 5 Nm; shielded lines are recommended for analog signals. The controller provides an RS-232 interface for PC or VT-100 terminal connections. Drive parameters and firmware are stored on a dedicated software module. Installation within a control cabinet is required, and supplemental air conditioning may be necessary depending on thermal load.

Technical Specifications

Version Code
2

Safety-Related Regulations Adherence
Yes

Earth Wire Connection Requirement
Yes

Feedback
Digital Servo and Resolver

Cooling
Heat Technology

Potential Additional Cooling
Air Conditioning

Firmware Mode
Software Module

Type Plate
Yes

Current Consumption
500mA at 24VDC

Maximum Operational Temperature
55°C

Water Penetration Protection
No

Positioning
Close As Possible to Power Supply

Terminals
A1, A2, A3

Terminal Screw Requirement
M6 with 5Nm Torque

Analog Signals Line Requirement
Shielded

Interface
RS 232 at X3 Connection Point
