R911290698 (DDS02.1-A100-RA02-02-FW)

DDS Drive Controllers

In Stock, Ships Today

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911290698 (DDS02.1-A100-RA02-02-FW) is a Bosch Rexroth drive controller compatible with LAR series AC motors, supporting resolver feedback for precise position sensing. It is protected to IP20 according to DIN VDE 0470 and is designed for operation at altitudes up to 1,000 m above sea level. The unit supports a rated current of 100 A and utilizes external cooling. Installation requires placement in a closed housing or control cabinet in accordance with national EMC standards. The controller prevents unauthorized or accidental operation and features dark current discharge exceeding 3.5 mA.

Technical Specifications

Feedback Type
Resolver

Protection Rating
IP 20

Installation Elevation
Maximum 1,000m over sea level

Function ID Code
01

Usage
Machine Tools

Installation
Only in Commercial Machinery

EMC Directives
Must Comply

Discharge Current
More than 3.5mA

De-energizing Method
Master Switch

Operation Caution
Do not touch electric connecting points when ON

Connections
Supports Four Plug-in Module at the bottom

Blower Connection Requirement
115V/230V Next to Another Controller

Connector Housing
To be shielded
