1070077610 (DMA 85B 4101-D)

DMA Servo Drive Modules

In Stock, Ships 2-3 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The 1070077610 (DMA 85B 4101-D) is a three-phase servo drive module designed with a Class A drive inverter, which may cause interference in residential environments. It features a non-regulated DC link voltage of 715 VDC, supports an analog interface with 16-bit resolution, and includes a standard encoder interface. The integrated IGBT output stage allows for automatic commissioning via electronic rating plates. Conforming to EN 50178 and EN 60204-1 standards, the module employs backplane cooling to limit heat accumulation. The processor board includes a ±10 V speed analog interface and a Ve-Con chip for digital speed, current, and position control with actual position value transmission. No additional modules are required for operation. Optimal performance is achieved when installed in IP54-rated switch cabinets with dust filtration, at altitudes below 1,000 m, and in conjunction with SR, SF, and DU motor series. Electrical specifications include 1.35 A at 24 VDC for current input, 670 V input voltage, and 400 V output voltage.

Technical Specifications

Drive Inverter Classification
Class A

Interference Risks
Possible in residential area

DC Link Voltage
715VDC

Interface
Analog with 16 bits resolution

Design
Modular

Output Stage
IGBT

Commissioning
Automatic with electronic rating plates

Cooling Mechanism
Air cooling in back plane mechanics

Additional Processor Board
Has +/-10V speed analog interface

Additional Modules
None

Maximum Power Loss
380W in the switch cabinet

Shock Resistance
15g according to DIN IEC 68-2-27

Circuit Protection Location
At the terminal strip

Installation Altitude
Not more than 1,000m above sea level.

Common Misspellings

1620 Old Apex Road
Cary, NC 27513, USA

Toll Free: 1-888-551-3082
International: 1-919-443-0207

Fax: 1-919-867-6204

[email protected]

Shipping & Payment Options

Warranty

Indramat USA 1 Year Warranty

Repair

We offer a repair service for the DMA 85B 4101-D.
