MHD071B-035-PP1-UN
MHD Synchronous Motors
Technical Specifications
Holding Brake
With holding brake
Holding Brake Torque
5.0 Nm
Housing Cooling Type
Liquid cooling
Encoder Type
Digital servo feedback w/ integrated encoder
Type of Position Detection
Absolute (>4096 revolutions)
Continuous Torque at Standstill
8.0 Nm
Motor Length
B
Centering diameter
95 mm
Flange size
115 mm
Motor Size
071
Shaft Design
Keyed Shaft
Shaft Seal
Yes
Power Connection Direction
turnable within a range of 270°
Power Connection Type
Power and feedback connectors
Product Type
Servo Motor
Winding Code
035
Frequently Asked Questions
Does the absolute encoder in the MHD071B-035-PP1-UN require homing at startup?
No, the absolute encoder retains position over power cycles, eliminating the need for homing. This improves cycle times and system reliability in automated operations.
Can this servo motor be used in high-precision robotic arms?
Yes, the digital feedback system and absolute position detection enable accurate motion control. It’s well-suited for tasks requiring tight path following and repeatability.
How does the 8.0 Nm continuous torque affect duty cycle planning?
It allows sustained operation at rated torque without derating. This is crucial for high-duty-cycle applications like packaging lines and continuous production systems.
Why is the MHD071B-035-PP1-UN equipped with a keyed shaft?
A keyed shaft ensures secure mechanical coupling and prevents slippage under load. It’s especially beneficial for torque transmission in indexing tables or gear-driven setups.
What is the significance of the integrated encoder and feedback connectors?
Combining encoder and power feedback minimizes wiring complexity and reduces potential failure points. It also streamlines commissioning and maintenance.
Common Misspellings
MHD 071B 035 PP1 UN
MHD 071B-035-PP1-UN
MHD-071B-035-PP1-UN
MHD071B035PP1UN
MHD07IB-035-PPI-UN
MHDO71B-O35-PP1-UN
MHD071B 035 PP1 UN
mhd071b-035-pp1-un
MHD71B-035-PP1-UN
Internal Product Review
The MHD071B-035-PP1-UN servo motor from Bosch Rexroth Indramat offers 8.0 Nm continuous torque and a 5.0 Nm holding brake. It features liquid cooling, absolute position detection (>4096 revolutions), and digital feedback. It is ideal for CNC machinery, robotics, packaging automation, and printing equipment.
