The MHD093B-035-NG1-RN servo motor by Bosch Rexroth Indramat is part of the MHD Synchronous Motors series. It features a liquid cooling housing, a digital servo feedback (HSF) encoder, and a relative position detection system, along with a holding brake torque of 22.0 Nm. It delivers a continuous torque at standstill of 17.5 Nm and uses a plain shaft with sealing. Its flange size of 140/150 mm ensures precise mounting.

Technical Specifications

Holding Brake
With holding brake

Holding Brake Torque
22.0 Nm

Housing Cooling Type
Liquid cooling

Encoder Type
Digital servo feedback (HSF)

Type of Position Detection
Relative

Continuous Torque at Standstill
17.5 Nm

Motor Length
B

Centering diameter
130 mm

Flange size
140 / 150 mm

Motor Size
093

Shaft Design
Plain shaft

Shaft Seal
Yes

Power Connection Direction
to the right

Power Connection Type
Power Connector

Product Type
Servo Motor

Winding Code
035
