MHD093B-035-PG2-AA
MHD Synchronous Motors
The MHD093B-035-PG2-AA is a servo motor from Bosch Rexroth Indramat’s MHD Synchronous Motors series. It uses digital servo feedback w/ integrated encoder with absolute (>4096 revolutions) position detection. This size 093 motor has a plain shaft with seal and delivers 17.5 Nm continuous torque at standstill plus 32.0 Nm holding brake torque. Cooling is by natural convection, mounting on a 140/150 mm flange with 130 mm centering diameter and side-A output connector power connection.
Technical Specifications
Holding Brake
With holding brake
Holding Brake Torque
32.0 Nm
Housing Cooling Type
Natural convection
Encoder Type
Digital servo feedback w/ integrated encoder
Type of Position Detection
Absolute (>4096 revolutions)
Continuous Torque at Standstill
17.5 Nm
Motor Length
B
Centering diameter
130 mm
Flange size
140 / 150 mm
Motor Size
093
Shaft Design
Plain shaft
Shaft Seal
Yes
Power Connection Direction
to side A
Power Connection Type
Output Connector
Product Type
Servo Motor
Winding Code
035
Frequently Asked Questions
What is the brake torque of MHD093B-035-PG2-AA?
The MHD093B-035-PG2-AA model features a brake torque of 32.0 Nm.
Where is the power connector located on MHD093B-035-PG2-AA?
The power connector for MHD093B-035-PG2-AA is on side A.
Does MHD093B-035-PG2-AA include a shaft seal?
Yes, MHD093B-035-PG2-AA comes with a shaft seal.
Which cooling type does MHD093B-035-PG2-AA use?
The MHD093B-035-PG2-AA uses natural convection.
What shaft design is found on MHD093B-035-PG2-AA?
The MHD093B-035-PG2-AA has a plain shaft.
