The MHD093B-058-NP1-AN from Bosch Rexroth Indramat is a high-performance Servo Motor in the MHD Synchronous Motors series. This MHD093B-058-NP1-AN design features a robust Keyed Shaft with integrated Shaft Seal and is equipped with a With holding brake delivering a reliable peak brake torque of 22.0 Nm. With a compact Motor Size of 093 and a Motor Length of B, it offers a centering diameter of 130 mm and flange size of 140 / 150 mm for standardized B05 mounting. The motor’s Winding Code of 058 ensures consistent electromagnetic characteristics and repeatable performance across varied industrial settings.
The motor’s electrical and feedback capabilities are highlighted by its Digital servo feedback (HSF) Encoder Type and Relative Type of Position Detection system, which deliver precise positioning and velocity control. Its continuous torque at standstill of 17.5 Nm enables reliable torque delivery during start-up and static holding. The Keyed Shaft design minimizes torsional backlash, while the Shaft Seal protects internal components from contaminants. Power is routed via an Output Connector oriented to side A, facilitating straightforward cable management and service access. Technical integration is further simplified by the motor’s standardized Flange size and Centering diameter, which align with common machine tool interfaces.
Operational resilience is assured through advanced Liquid cooling housing that dissipates heat effectively, maintaining optimal thermal conditions under heavy duty cycles. The With holding brake supports dynamic stop-and-hold functionality, reducing cycle times in automated applications. Combined with the motor’s low moment of inertia inherent in the MHD093B-058-NP1-AN design, repeatable high-frequency start-stop operations can be executed without sacrificing precision. The Digital servo feedback (HSF) encoder continuously monitors rotor position, enabling real-time adjustments and reducing overshoot. Installation is streamlined by the motor’s standard B05 flange mounting and adherence to industry-defined power connection protocols.
Engineers can readily integrate the MHD093B-058-NP1-AN into existing motion control architectures through its compatibility with Bosch Rexroth’s drive electronics and standardized power connection type. The Output Connector on side A allows direct interfacing with 200–347 VAC supplies, minimizing adaptation hardware. Thanks to its precise feedback loop and compact footprint, this motor is ideal for robotics, packaging machinery, CNC indexing tables, and high-speed assembly lines. Its combination of robust thermal management, high brake torque, and accurate position detection make it a versatile solution for demanding automation environments.
Holding Brake
With holding brake
Holding Brake Torque
22.0 Nm
Housing Cooling Type
Liquid cooling
Encoder Type
Digital servo feedback (HSF)
Type of Position Detection
Relative
Continuous Torque at Standstill
17.5 Nm
Motor Length
B
Centering diameter
130 mm
Flange size
140 / 150 mm
Motor Size
093
Shaft Design
Keyed Shaft
Shaft Seal
Yes
Power Connection Direction
to side A
Power Connection Type
Output Connector
Product Type
Servo Motor
Winding Code
058
