MHD093B-058-PP0-AA
MHD Synchronous Motors
The Bosch Rexroth Indramat MHD093B-058-PP0-AA is a servo motor from the MHD Synchronous Motors series, delivering 17.5 Nm continuous torque at standstill with digital servo feedback and absolute position detection over 4096 revolutions. It uses natural convection cooling and flange sizes of 140/150 mm.
Technical Specifications
Holding Brake
Without holding brake
Housing Cooling Type
Natural convection
Encoder Type
Digital servo feedback w/ integrated encoder
Type of Position Detection
Absolute (>4096 revolutions)
Continuous Torque at Standstill
17.5 Nm
Motor Length
B
Centering diameter
130 mm
Flange size
140 / 150 mm
Motor Size
093
Shaft Design
Keyed Shaft
Shaft Seal
Yes
Power Connection Direction
to side A
Power Connection Type
Output Connector
Product Type
Servo Motor
Winding Code
058
Frequently Asked Questions
What shaft design is included in the MHD093B-058-PP0-AA motor?
The MHD093B-058-PP0-AA motor has a keyed shaft.
Does the MHD093B-058-PP0-AA motor come with a holding brake?
The MHD093B-058-PP0-AA motor is supplied without a holding brake.
What type of cooling does the MHD093B-058-PP0-AA motor use?
The MHD093B-058-PP0-AA motor uses natural convection.
Where is the power connector on the MHD093B-058-PP0-AA motor?
The MHD093B-058-PP0-AA motor has its connector on side A.
Which winding code applies to the MHD093B-058-PP0-AA motor?
The MHD093B-058-PP0-AA motor uses winding code 058.
Common Misspellings
MHD093B058PP0AA
MHD093B 058 PP0 AA
mhd093b-058-pp0-aa
MHD93B-058-PP0-AA
Internal Product Review
The MHD093B-058-PP0-AA is well regarded for its stable operation and straightforward integration. Users highlight its reliable performance in daily use. It functions smoothly without frequent adjustments, making it a practical choice for consistent and dependable operation in different setups.
