MHD093C-024-NG1-AA

Name: MHD093C-024-NG1-AA
Brand: Indramat Motors
SKU: MHD093C-024-NG1-AA
Price: 872.00 USD
Availability: InStock

MHD Synchronous Motors

Front Right

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

3 Minutes 31 Seconds

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The MHD093C-024-NG1-AA is a servo motor from Bosch Rexroth Indramat’s MHD Synchronous Motors series. It offers a continuous torque at standstill of 23.0 Nm and a holding brake torque of 22.0 Nm, featuring a holding brake and plain shaft with shaft seal. Natural convection housing cooling and a digital servo feedback (HSF) relative encoder ensure reliable operation. This 093-size motor with a 130 mm centering diameter and 140 / 150 mm flange uses a side A output connector and winding code 024.

Technical Specifications

Holding Brake
With holding brake

Holding Brake Torque
22.0 Nm

Housing Cooling Type
Natural convection

Encoder Type
Digital servo feedback (HSF)

Type of Position Detection
Relative

Continuous Torque at Standstill
23.0 Nm

Motor Length
C

Centering diameter
130 mm

Flange size
140 / 150 mm

Motor Size
093

Shaft Design
Plain shaft

Shaft Seal
Yes

Power Connection Direction
to side A

Power Connection Type
Output Connector

Product Type
Servo Motor

Winding Code
024

Frequently Asked Questions

Does the MHD093C-024-NG1-AA motor include a holding brake?

Yes, the MHD093C-024-NG1-AA motor has a 22.0 Nm brake.

Which cooling method is used for the MHD093C-024-NG1-AA motor?

The MHD093C-024-NG1-AA motor uses natural convection.

What is the shaft type of the MHD093C-024-NG1-AA motor?

The MHD093C-024-NG1-AA motor uses a plain shaft.

Where is the power connector on the MHD093C-024-NG1-AA motor?

The MHD093C-024-NG1-AA motor has its connection on side A.

What winding code is assigned to the MHD093C-024-NG1-AA motor?

The MHD093C-024-NG1-AA motor uses code 024.

Common Misspellings

MHD093C024NG1AA

MHD093C 024 NG1 AA

mhd093c-024-ng1-aa

MHD93C-024-NG1-AA

Internal Product Review

The MHD093C-024-NG1-AA offers balanced performance in continuous-duty environments. Its overall design supports long-term operation. The structure allows stable integration into different setups. It performs without disruptions through extended use. Many industries rely on its stable operation. It stands out for maintaining consistent results, even during demanding cycles.
