MHD093C-058-NP0-AN
MHD Synchronous Motors
Technical Specifications
Holding Brake
Without holding brake
Housing Cooling Type
Liquid cooling
Encoder Type
Digital servo feedback (HSF)
Type of Position Detection
Relative
Continuous Torque at Standstill
23.0 Nm
Motor Length
C
Centering diameter
130 mm
Flange size
140 / 150 mm
Motor Size
093
Shaft Design
Keyed Shaft
Shaft Seal
Yes
Power Connection Direction
to side A
Power Connection Type
Output Connector
Product Type
Servo Motor
Winding Code
058
Frequently Asked Questions
How does the side A power connector configuration of the MHD093C-058-NP0-AN improve installation flexibility?
The side A connector orientation simplifies cable routing and reduces interference with other machine components. It helps achieve a cleaner and more compact setup in tight mounting spaces.
Why is a digital servo feedback (HSF) encoder used in the MHD093C-058-NP0-AN model?
The HSF encoder provides precise position feedback for dynamic motion control. It ensures accurate synchronization between the drive and motor for smoother and more responsive operation.
How does the keyed shaft with a shaft seal benefit the MHD093C-058-NP0-AN motor in industrial use?
The keyed shaft ensures a secure mechanical connection with the load, preventing slippage under torque. The shaft seal protects internal components from contamination, enhancing durability in harsh environments.
What advantage does the relative position detection system offer in the MHD093C-058-NP0-AN motor?
Relative position detection reduces the complexity of initial setup and recalibration. It allows the system to track motion effectively without requiring an absolute reference point each time.
What are the benefits of omitting a holding brake in the MHD093C-058-NP0-AN design?
Without a holding brake, the motor has a simpler mechanical structure and lower inertia. This allows for faster acceleration and deceleration, ideal for high-speed automation tasks.
Common Misspellings
MHD093C058NP0AN
MHD093C 058 NP0 AN
mhd093c-058-np0-an
MHD93C-058-NP0-AN
Internal Product Review
The MHD093C-058-NP0-AN servo motor from Bosch Rexroth features liquid cooling, a keyed shaft, and a digital servo feedback (HSF) encoder with relative position detection. It delivers 23.0 Nm continuous torque at standstill and comes without a holding brake. This motor is well-suited for applications in robotics, packaging machinery, and CNC machining systems.
