MHD093C-058-NP1-AN
MHD Synchronous Motors
MHD093C-058-NP1-AN, Bosch Rexroth Indramat, MHD Synchronous Motors present a high-performance servo solution designed for demanding industrial automation. The compact Motor Size 093 unit features a robust Liquid cooling housing that maintains thermal stability under continuous operation. With an integrated Digital servo feedback (HSF) encoder, the MHD093C delivers precise position information with Relative detection accuracy. Its streamlined design accommodates a side-mounted power connection for flexible installation in confined machine spaces.
Engineered for holding and motion tasks, this servo motor incorporates a built-in Holding Brake rated at 22.0 Nm torque, ensuring secure load retention when idle. The continuous torque at standstill of 23.0 Nm provides substantial holding capacity, while the Keyed Shaft and Shaft Seal protect internal components from contamination. The motor’s flange supports both 140 / 150 mm mounting patterns and a Centering diameter 130 mm for direct-coupled applications. A modular Output Connector on side A simplifies power and feedback wiring, and the standardized Winding Code 058 ensures compatibility with Rexroth drive amplifiers.
As a fully enclosed Servo Motor, the MHD093C-058-NP1-AN integrates seamlessly into Rexroth motion control architectures, enabling rapid commissioning via automated parameter matching. The combination of liquid cooling and sealed shaft design guarantees long-term reliability in high-duty-cycle processes. Ideal for servo presses, rotary indexing tables, and robotic joints, this motor maximizes uptime and precision in demanding production environments.
Technical Specifications
Holding Brake
With holding brake
Holding Brake Torque
22.0 Nm
Housing Cooling Type
Liquid cooling
Encoder Type
Digital servo feedback (HSF)
Type of Position Detection
Relative
Continuous Torque at Standstill
23.0 Nm
Motor Length
C
Centering diameter
130 mm
Flange size
140 / 150 mm
Motor Size
093
Shaft Design
Keyed Shaft
Shaft Seal
Yes
Power Connection Direction
to side A
Power Connection Type
Output Connector
Product Type
Servo Motor
Winding Code
058
