MHD093C-058-PG1-AN
MHD Synchronous Motors
Technical Specifications
Holding Brake
With holding brake
Holding Brake Torque
22.0 Nm
Housing Cooling Type
Liquid cooling
Encoder Type
Digital servo feedback w/ integrated encoder
Type of Position Detection
Absolute (>4096 revolutions)
Continuous Torque at Standstill
23.0 Nm
Motor Length
C
Centering diameter
130 mm
Flange size
140 / 150 mm
Motor Size
093
Shaft Design
Plain shaft
Shaft Seal
Yes
Power Connection Direction
to side A
Power Connection Type
Output Connector
Product Type
Servo Motor
Winding Code
058
Frequently Asked Questions
What is the benefit of the liquid cooling system in the MHD093C-058-PG1-AN motor?
The liquid cooling system efficiently dissipates heat, allowing continuous high torque operation without overheating. This ensures longer motor life and stable performance under heavy-duty cycles.
Why does the MHD093C-058-PG1-AN use a plain shaft design?
A plain shaft provides precise torque transmission and easy integration with various coupling systems. It minimizes backlash, making it ideal for high-accuracy motion control tasks.
How does the integrated digital servo feedback encoder enhance performance in the MHD093C-058-PG1-AN?
The integrated encoder provides real-time position and speed feedback to the drive controller. This results in smoother motion control and higher positional accuracy during dynamic operations.
What advantage does the side-A power connection of the MHD093C-058-PG1-AN offer in system installation?
The side-A power connection simplifies cable routing and improves accessibility in compact machinery layouts. It also reduces installation space and enhances maintenance convenience.
How does the holding brake torque of the MHD093C-058-PG1-AN improve system safety?
The 22 Nm holding brake torque securely holds the load during power-off or emergency stops. This feature prevents unintended motion, ensuring operator and equipment safety.
Common Misspellings
MHD093C058PG1AN
MHD093C 058 PG1 AN
mhd093c-058-pg1-an
MHD93C-058-PG1-AN
Internal Product Review
The MHD093C-058-PG1-AN servo motor from Bosch Rexroth features a continuous standstill torque of 23.0 Nm and includes a 22.0 Nm holding brake. It uses liquid cooling and absolute digital servo feedback with an integrated encoder. This motor is well-suited for automation in robotics, CNC machinery, and packaging lines.
Shipping & Payment Options
Warranty
Repair
We offer a repair service for the MHD093C-058-PG1-AN.
