MHD093C-058-PP0-AA

MHD Synchronous Motors

  In Stock, Ships Today
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

The Bosch Rexroth Indramat MHD093C-058-PP0-AA from the MHD Synchronous Motors series is a robust servo motor designed for precision control in demanding industrial applications. This MHD093C-058-PP0-AA model features a Motor Size 093 frame, a Centering diameter of 130 mm, and a versatile Flange size of 140/150 mm for secure mounting. Its compact profile, with a Motor Length C, delivers a high power density while preserving valuable cabinet space. Constructed with a rugged Keyed Shaft and a reliable Shaft Seal, this unit ensures mechanical stability and longevity under cyclic loads.



The motor's thermal management is handled by natural convection cooling, allowing a continuous torque rating of 23.0 Nm at standstill without auxiliary cooling equipment. It incorporates a digital servo feedback w/ integrated encoder that delivers absolute (>4096 revolutions) position detection, enabling precise motion control and repeatability. The built-in encoder supports multiturn feedback for position tracking, eliminating drift and facilitating rapid commissioning. Wound with a Winding Code 058 configuration, the motor maintains consistent performance across a rated voltage range of 168-302 V and frequencies between 133-233 Hz.



Power is supplied via an output connector located on side A, simplifying cable routing and serviceability. The design omits a holding brake, categorized as Without holding brake, reducing component count and maintenance points. Certified as a Product Type: Servo Motor, the MHD093C-058-PP0-AA delivers continuous current ratings from 28.3 A (natural convection) to 42.5 A (surface cooling), with peak torques reaching 34.5 Nm under forced cooling conditions. Its precision encoder and robust mechanical interface make it ideal for machine tools, automation systems, and handling equipment where high kinetics and start/stop duty are critical.

Technical Specifications

Holding Brake
Without holding brake

Housing Cooling Type
Natural convection

Encoder Type
Digital servo feedback w/ integrated encoder

Type of Position Detection
Absolute (>4096 revolutions)

Continuous Torque at Standstill
23.0 Nm

Motor Length
C

Centering diameter
130 mm

Flange size
140 / 150 mm

Motor Size
093

Shaft Design
Keyed Shaft

Shaft Seal
Yes

Power Connection Direction
to side A

Power Connection Type
Output Connector

Product Type
Servo Motor

Winding Code
058
