MHD112B-024-NG0-LN
MHD Synchronous Motors
Technical Specifications
Holding Brake
Without holding brake
Housing Cooling Type
Liquid cooling
Encoder Type
Digital servo feedback (HSF)
Type of Position Detection
Relative
Continuous Torque at Standstill
28.0 Nm
Motor Length
B
Centering diameter
130 mm
Flange size
192 mm
Motor Size
112
Shaft Design
Plain shaft
Shaft Seal
Yes
Power Connection Direction
to the left
Power Connection Type
Power Connector
Product Type
Servo Motor
Winding Code
024
Frequently Asked Questions
What are the installation considerations for the power connector positioned to the left?
Cabling must be routed to avoid strain or interference with moving machine parts. Proper clearance ensures easier maintenance and reliable electrical connections.
What is the role of relative position detection in control accuracy?
Relative encoders require homing at startup to establish reference position. Once initialized, they deliver precise incremental tracking for closed-loop control.
Can the MHD112B-024-NG0-LN operate in dusty or humid environments?
Yes, if properly sealed and integrated with its shaft seal and housing protection. Adequate enclosure and coolant system integrity are key to reliable operation.
What benefits does a continuous torque of 28 Nm provide in servo applications?
It supports high-load processes like pressing or rotary indexing without torque drop. This ensures consistent performance during long duty cycles.
Why is a plain shaft design preferred in some automation setups?
Plain shafts simplify coupling with gearboxes or pulleys and reduce alignment complexity. However, they rely on external retention systems for axial load handling.
Common Misspellings
MHD112B024NG0LN
MHD112B 024 NG0 LN
mhd112b-024-ng0-ln
Internal Product Review
The MHD112B-024-NG0-LN is an industrial servo motor from the Bosch Rexroth Indramat MHD series. It offers liquid cooling, a digital HSF encoder, and 28.0 Nm continuous torque at standstill with a 192 mm flange. Its housing is designed for liquid cooling, which enables efficient heat dissipation and stable operation in demanding environments.
