MHD112B-024-NP0-RN, Bosch Rexroth Indramat, MHD Synchronous Motors series servo motor delivers precision motion control in a robust, industrial-grade package. Designed as a Product Type with a compact Motor Size of 112 and a keyed Shaft Design on a 130 mm Centering diameter, it integrates effortlessly into multi-axis systems. The housing features Housing Cooling Type for efficient thermal management, while a durable Shaft Seal ensures protection against contaminants. With a lightweight, modular form factor, the motor balances high performance and space-saving installation.
Boasting a Continuous Torque at Standstill of 28.0 Nm and a rated continuous torque of 42 Nm at 32.9 A, this motor sustains smooth torque delivery across its 0–2000 rpm continuous speed range. At peak operation, it reaches 3500 rpm under a maximum current of 98.5 A. Feedback is provided by a high-resolution Encoder Type with multiturn absolute functionality, supporting Type of Position Detection for precise closed-loop control. The motor’s Power Connection Type via right-oriented Power Connection Direction connector simplifies wiring, while a standard 192 mm Flange size ensures compatibility with existing mounts. Its Winding Code 024 coil set delivers optimal electromagnetic performance, and optional air-blower retrofit enhances thermal headroom in demanding applications.
Engineers benefit from seamless integration of the MHD112B-024-NP0-RN into Rexroth drive ecosystems, where plug-and-play parameterization accelerates commissioning. The liquid-cooled design and sealed bearings deliver long-term reliability in harsh environments, reducing maintenance cycles. Ideal for metalworking, packaging, and process automation, this motor excels where precise torque, repeatable positioning, and rugged durability are paramount.
Holding Brake
Without holding brake
Housing Cooling Type
Liquid cooling
Encoder Type
Digital servo feedback (HSF)
Type of Position Detection
Relative
Continuous Torque at Standstill
28.0 Nm
Motor Length
B
Centering diameter
130 mm
Flange size
192 mm
Motor Size
112
Shaft Design
Keyed Shaft
Shaft Seal
Yes
Power Connection Direction
to the right
Power Connection Type
Power Connector
Product Type
Servo Motor
Winding Code
024
