MHD112B-024-PG1-RN

MHD Synchronous Motors

  In Stock, Ships Today
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

MHD112B-024-PG1-RN, manufactured by Bosch Rexroth Indramat and part of the MHD Synchronous Motors lineup, is a high-performance servo motor engineered for precision and durability. This model integrates a robust Product Type: Servo Motor architecture with a compact Motor Size: 112 format, delivering consistent performance in demanding industrial settings. Equipped with a Winding Code: 024 and featuring a high-resolution Encoder Type: Digital servo feedback w/ integrated encoder, the MHD112B-024-PG1-RN ensures accurate position control across a wide speed range. A plain Shaft Design: Plain shaft with integrated Shaft Seal: Yes safeguards the drive train while maintaining service simplicity.



In operation, the motor provides a Continuous Torque at Standstill: 28.0 Nm and supports a peak holding capability of Holding Brake Torque: 22.0 Nm courtesy of its built-in Holding Brake: With holding brake module. The Housing Cooling Type: Liquid cooling system manages thermal loads effectively, ensuring stable operation under heavy duty cycles. Precision alignment is supported by the Centering diameter: 130 mm and Flange size: 192 mm mounting features, while absolute position feedback spans over 4096 revolutions as defined by the Type of Position Detection: Absolute (>4096 revolutions) spec. Power is routed through a right-angled Power Connection Direction: to the right Power Connection Type: Power Connector, facilitating straightforward cabling in compact installations.



Engineers will appreciate the motor’s seamless integration into multi-axis drives and CNC systems, driven by its industry-standard digital encoder interface. The sealed shaft design, liquid cooling, and comprehensive position detection combine to deliver reliable, long-term performance even in high-precision automation applications. With its balanced mix of torque density, feedback accuracy, and robust construction, the MHD112B-024-PG1-RN stands out as an ideal choice for packaging, robotics, and material handling equipment.

Technical Specifications

Holding Brake
With holding brake

Holding Brake Torque
22.0 Nm

Housing Cooling Type
Liquid cooling

Encoder Type
Digital servo feedback w/ integrated encoder

Type of Position Detection
Absolute (>4096 revolutions)

Continuous Torque at Standstill
28.0 Nm

Motor Length
B

Centering diameter
130 mm

Flange size
192 mm

Motor Size
112

Shaft Design
Plain shaft

Shaft Seal
Yes

Power Connection Direction
to the right

Power Connection Type
Power Connector

Product Type
Servo Motor

Winding Code
024
