MHD112B-024-PP0-BN
MHD Synchronous Motors
The MHD112B-024-PP0-BN is a servo motor by Bosch Rexroth Indramat in the MHD Synchronous Motors series. It delivers 28.0 Nm continuous torque at standstill and reaches 4000 RPM. Featuring liquid cooling or natural convection cooling, it employs digital servo feedback w/ integrated encoder with absolute (>4096 revolutions) detection. Housed in an IP65 enclosure with a 192 mm flange, 130 mm centering diameter, keyed shaft, side B output connector, it weighs 34 kg.
Technical Specifications
Holding Brake
Without holding brake
Housing Cooling Type
Liquid cooling
Encoder Type
Digital servo feedback w/ integrated encoder
Type of Position Detection
Absolute (>4096 revolutions)
Continuous Torque at Standstill
28.0 Nm
Motor Length
B
Centering diameter
130 mm
Flange size
192 mm
Motor Size
112
Shaft Design
Keyed Shaft
Shaft Seal
Yes
Power Connection Direction
to side B
Power ConnectionType
Output Connector
Product Type
Servo Motor
Winding Code
024
Cooling
Natural convection or surface cooling
Maximum speed
4000 RPM
Protection rating
IP65
Weight
34 kg
Frequently Asked Questions
Does the MHD112B-024-PP0-BN include a brake?
The MHD112B-024-PP0-BN does not include a brake.
What is the maximum speed of the MHD112B-024-PP0-BN?
The MHD112B-024-PP0-BN can reach 4000 RPM.
What is the protection rating of the MHD112B-024-PP0-BN?
The MHD112B-024-PP0-BN has IP65 protection.
What is the weight of the MHD112B-024-PP0-BN?
The MHD112B-024-PP0-BN weighs 34 kg.
What cooling is supported by the MHD112B-024-PP0-BN?
The MHD112B-024-PP0-BN supports natural convection or surface cooling.
Common Misspellings
MHD 112B-024-PP0-BN
MHD-112B-024-PP0-BN
MHD112B 024 PP0 BN
MHD112B-O24-PPO-BN
MHD112B024PP0BN
MHDII2B-024-PP0-BN
mhd112b-024-pp0-bn
MHD112B024PP0BN
Internal Product Review
The MHD112B-024-PP0-BN has gained trust for its efficient operation and ability to perform consistently. Customers note that it integrates well into existing setups, providing stable functionality. Its reliability stands out during extended usage. Operators value the assurance it provides, making it a frequently chosen option for those seeking smooth workflows.
