MHD112B-035-PP2-AN
MHD Synchronous Motors
The MHD112B-035-PP2-AN from Bosch Rexroth Indramat features liquid cooling and a holding brake torque of 32.0 Nm. Part of the MHD Synchronous Motors series, it uses a keyed shaft design and offers absolute position detection with over 4096 revolutions. This servo motor has a multiturn encoder and delivers 28.0 Nm continuous torque at standstill.
It has side A power connection and a shaft seal. Flange size is 192 mm. Centering diameter is 130 mm.
Technical Specifications
Holding Brake
With holding brake
Holding Brake Torque
32.0 Nm
Housing Cooling Type
Liquid cooling
Encoder Type
Digital servo feedback w/ integrated encoder
Type of Position Detection
Absolute (>4096 revolutions)
Continuous Torque at Standstill
28.0 Nm
Motor Length
B
Centering diameter
130 mm
Flange size
192 mm
Motor Size
112
Shaft Design
Keyed Shaft
Shaft Seal
Yes
Power Connection Direction
to side A
Power Connection Type
Output Connector
Product Type
Servo Motor
Winding Code
035
Frequently Asked Questions
What protection does the mechanical interface provide in load-bearing drive applications?
The keyed shaft ensures firm torque transmission and secure coupling. It resists rotational slippage under variable mechanical loads.
How does the MHD112B-035-PP2-AN handle heat buildup during high-torque duty cycles?
Liquid cooling maintains thermal equilibrium under sustained torque output. It enables consistent performance without heat-induced degradation.
Can this model provide safe load retention during uncontrolled stops or vertical axis downtime?
A 32 Nm holding brake secures the drive against unintentional movement. It preserves positioning accuracy when motion control is disabled.
How does feedback resolution influence axis precision in servo-controlled environments?
Digital encoder feedback with absolute detection over 4096 counts ensures accurate real-time position monitoring. It supports high-resolution motion profiling.
Is the MHD112B-035-PP2-AN appropriate for stable torque output at zero speed?
It delivers 28 Nm continuous torque at standstill for load holding and process consistency. This supports applications requiring zero-speed control under load.
Common Misspellings
MHD112B035PP2AN
MHD112B 035 PP2 AN
mhd112b-035-pp2-an
Internal Product Review
The model MHD112B-035-PP2-AN is a precision-engineered servo motor with a 32 Nm holding brake. It offers 28 Nm continuous torque, digital feedback, a keyed shaft for secure coupling, and high-resolution absolute position detection. This Bosch motor offers advanced liquid cooling that ensures optimal performance in high-demand industrial applications.
