MHD112B-048-PP1-AN
MHD Synchronous Motors
The MHD112B-048-PP1-AN is a servo motor by Bosch Rexroth Indramat in the MHD Synchronous Motors series. It features liquid cooling and digital servo feedback w/ integrated encoder with absolute position detection over 4096 revolutions. Equipped with a holding brake of 22.0 Nm and 28.0 Nm standstill torque, the size 112 motor features a 130 mm centering diameter, 192 mm flange, keyed shaft with seal and side-A power connector.
Technical Specifications
Holding Brake
With holding brake
Holding Brake Torque
22.0 Nm
Housing Cooling Type
Liquid cooling
Encoder Type
Digital servo feedback w/ integrated encoder
Type of Position Detection
Absolute (>4096 revolutions)
Continuous Torque at Standstill
28.0 Nm
Motor Length
B
Centering diameter
130 mm
Flange size
192 mm
Motor Size
112
Shaft Design
Keyed Shaft
Shaft Seal
Yes
Power Connection Direction
to side A
Power Connection Type
Output Connector
Product Type
Servo Motor
Winding Code
048
Frequently Asked Questions
Can this model be installed directly into standard servo platforms without custom brackets?
Its 192 mm flange and 130 mm centering diameter follow industrial mounting standards. This enables precise, repeatable alignment in modular automation systems.
How does the MHD112B-048-PP1-AN protect against shaft contamination in exposed setups?
The keyed shaft includes a protective seal to block dust and fluids. This ensures mechanical integrity and extends service life in harsh environments.
Is it possible to resume motion tasks without re-homing after power interruptions?
The integrated digital encoder provides absolute position detection over 4096+ revolutions. It retains position memory across shutdowns for uninterrupted control.
How is thermal stability maintained during long periods of full-torque operation?
A liquid-cooled housing actively regulates core temperature. This prevents performance degradation in tightly enclosed or high-load duty cycles.
What safety measure supports shaft locking in powered-off conditions?
A 22.0 Nm holding brake secures the rotor during idle states. It prevents load shift or drop in vertical or suspended load systems.
Common Misspellings
MHD112B048PP1AN
MHD112B 048 PP1 AN
mhd112b-048-pp1-an
Internal Product Review
The model MHD112B-048-PP1-AN is a robust servo motor equipped with a keyed shaft and seal. This Bosch model boasts liquid cooling, a 22.0 Nm holding brake, 28.0 Nm standstill torque, and a side-A power connector for streamlined installation. Its integrated encoder supports absolute position detection across 4096+ revolutions.
