MHD112B-058-NP1-BN
MHD Synchronous Motors
Technical Specifications
Holding Brake
With holding brake
Holding Brake Torque
22.0 Nm
Housing Cooling Type
Liquid cooling
Encoder Type
Digital servo feedback (HSF)
Type of Position Detection
Relative
Continuous Torque at Standstill
28.0 Nm
Motor Length
B
Centering diameter
130 mm
Flange size
192 mm
Motor Size
112
Shaft Design
Keyed Shaft
Shaft Seal
Yes
Power Connection Direction
to side B
Power ConnectionType
Output Connector
Product Type
Servo Motor
Winding Code
058
Frequently Asked Questions
What type of encoder feedback does the MHD112B-058-NP1-BN offer during motion control tasks?
The motor features a digital HSF encoder with relative position detection. This requires homing after power cycles to restore accurate positional tracking.
How is torque performance handled during non-rotational load holding?
The motor delivers 28.0 Nm continuous torque at standstill. This supports static force applications without compromising positional stability.
How does the motor ensure reliable load retention in vertical motion systems?
A 22.0 Nm holding brake locks the shaft during power-off states. This adds safety by preventing unintended movement or load drift.
What design element ensures stable mechanical engagement in reversing-load conditions?
The keyed shaft with shaft seal provides rigid torque transfer and ingress protection. It maintains connection integrity in dynamic environments.
Can this model support rear-side cable routing in tight control panel configurations?
Its side B power connector allows direct, rear-facing cable exit. This simplifies wiring in machines with rear-mounted drives or limited front access.
Common Misspellings
MHD112B058NP1BN
MHD112B 058 NP1 BN
mhd112b-058-np1-bn
Internal Product Review
The Rexroth Indramat MHD112B-058-NP1-BN servo motor features a keyed shaft with shaft seal for secure power transmission. It offers liquid cooling, 28.0 Nm standstill torque, a 22.0 Nm holding brake, and HSF encoder with relative position feedback. It is perfectly suited for robotics, packaging, and automated assembly lines.
