MHD112C-024-NP0-BN

MHD Synchronous Motors

Rated 4.5 stars (7 total reviews)

In Stock, Ships Today

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

5 Minutes 11 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The MHD112C-024-NP0-BN is a 45 kg AC servo motor with a keyed shaft. Manufactured by Bosch Rexroth Indramat in the Motors series, it delivers 38.0 Nm continuous torque and reaches a rated speed of 2500 RPM. The motor features a liquid cooled housing, digital servo feedback encoder, and offers a maximum speed of 4000 RPM.

Technical Specifications

Holding Brake
Without holding brake

Housing Cooling Type
Liquid cooling

Encoder Type
Digital servo feedback (HSF)

Type of Position Detection
Relative

Continuous Torque at Standstill
38.0 Nm

Motor Length
C

Centering diameter
130 mm

Flange size
192 mm

Motor Size
112

Shaft Design
Keyed Shaft

Shaft Seal
Yes

Power Connection Direction
to side B

Power ConnectionType
Output Connector

Product Type
Servo Motor

Winding Code
024

Cooling
Natural convection or surface cooling

Insulation
Class F

Maximum speed
4000 RPM

Rated speed
2500 RPM

Weight
45 kg

Frequently Asked Questions

Common Misspellings

Internal Product Review

The MHD112C-024-NP0-BN continues to be chosen for its smooth performance and dependable function. Customers often mention how it maintains consistency, which helps workflows remain efficient. Operators highlight its trustworthy design, which ensures confidence during extended use. This model is regularly recommended as a reliable choice for professional environments and tasks.
