MHD112C-035-NP0-LN
MHD Synchronous Motors
The Bosch Rexroth Indramat MHD112C-035-NP0-LN from the MHD Synchronous Motors series is a robust servo motor featuring liquid cooling, a winding code of 035, and a digital servo feedback (HSF) encoder type. It delivers a continuous standstill torque of 38.0 Nm, with a keyed shaft design and integrated shaft seal for reliable operation. The motor size is 112 with a centering diameter of 130 mm and a flange size of 192 mm. Power connection is via a left-oriented power connector, and this model operates without a holding brake, providing flexible integration for high-precision industrial applications.
Technical Specifications
Holding Brake
Without holding brake
Housing Cooling Type
Liquid cooling
Encoder Type
Digital servo feedback (HSF)
Type of Position Detection
Relative
Continuous Torque at Standstill
38.0 Nm
Motor Length
C
Centering diameter
130 mm
Flange size
192 mm
Motor Size
112
Shaft Design
Keyed Shaft
Shaft Seal
Yes
Power Connection Direction
to the left
Power Connection Type
Power Connector
Product Type
Servo Motor
Winding Code
035
Frequently Asked Questions
How does the winding code on MHD112C-035-NP0-LN influence electrical sizing and torque capability?
The winding code 035 maps to a 3000 min⁻¹ characteristic speed, 38 Nm standstill torque (natural cooling) and 1.37 Nm/A torque constant for guiding drive current and dc-bus requirements. Its rated speed is 2500 rpm with 167 Hz rated frequency for sizing filters and mechanics.
Why does the MHD112C-035-NP0-LN use HSF digital servo feedback, and what does “relative” imply?
The HSF provides high-resolution incremental signals for precise velocity and position loops with low latency. It’s relative axis requires a homing/reference move after power-down to establish absolute position.
What’s the impact of liquid-cooled housing (series feature) on thermal utilization for this motor family?
Its liquid-cooled housings in the MHD series remove heat efficiently to enabling higher continuous output and temperature stability under sustained load compared with natural convection. Its coolant-ready variants are documented across the family.
How does the IP65 enclosure of the MHD112C-035-NP0-LN affect installation environments?
The IP65 protects against dust ingress and low-pressure water jets, supporting use near coolants or airborne particulates typical of packaging lines and machining cells. It still requires appropriate cable glands and sealed connectors to maintain the rating.
What are the mechanical interface points and why do they matter?
The size-112 frame standardizes a 192 mm flange and 130 mm centering diameter for drop-in interchangeability across MHD112 variants. It eases retrofits and ensures concentricity for precision couplings and gearheads.
Common Misspellings
MHD112C035NP0LN
MHD112C 035 NP0 LN
mhd112c-035-np0-ln
Internal Product Review
The Rexroth Indramat’s MHD112C-035-NP0-LN servo motor combines size-112 mechanics with winding code 035, HSF relative feedback and a sealed keyed shaft. It delivers 38 Nm at standstill and possess IP65 protection rating to safe guard against external pollutants. It is suitable for packaging, printing and machine-tool feed axes that requires precise positioning and continuous duty.
