MHD115B-024-PP0-AA

MHD Synchronous Motors

In Stock, Ships 2-3 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

4 Minutes 45 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The MHD115B-024-PP0-AA servo motor operates without a holding brake, uses natural convection housing cooling, features digital servo feedback with integrated encoder, and provides absolute position detection over 4096 revolutions. Part of MHD Synchronous Motors by Bosch Rexroth Indramat, it delivers 50.0 Nm standstill torque.

Technical Specifications

Holding Brake
Without holding brake

Housing Cooling Type
Natural convection

Encoder Type
Digital servo feedback w/ integrated encoder

Type of Position Detection
Absolute (>4096 revolutions)

Continuous Torque at Standstill
50.0 Nm

Motor Length
B

Centering diameter
180 mm

Flange size
192 mm

Motor Size
115

Shaft Design
Keyed Shaft

Shaft Seal
Yes

Power Connection Direction
to side A

Power Connection Type
Output Connector

Product Type
Servo Motor

Winding Code
024

Common Misspellings

1620 Old Apex Road
Cary, NC 27513, USA

Toll Free: 1-888-551-3082
International: 1-919-443-0207

Fax: 1-919-867-6204

[email protected]

Shipping & Payment Options

Warranty

Indramat USA 1 Year Warranty

Repair

We offer a repair service for the MHD115B-024-PP0-AA.

Exchange

Want to sell your MHD115B-024-PP0-AA?
