R911273522 (MHD093B-058-PG0-AN)

Name: R911273522 (MHD093B-058-PG0-AN)
Brand: Indramat Motors
SKU: MHD093B-058-PG0-AN
Price: 320.00 USD
Availability: InStock

MHD Synchronous Motors

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

6 Minutes 15 Seconds

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911273522 (MHD093B-058-PG0-AN) is a Rexroth Indramat synchronous servo motor designed for industrial applications, converting electrical energy to mechanical motion. This MPN features a brushless design with a permanent magnet rotor, supporting high torque-to-mass ratio and low noise operation. The motor achieves a continuous standstill torque of 17.5 Nm, nominal speed of 4000 RPM at 30 A, and a peak speed of 6000 RPM at 101.2 A. It incorporates liquid cooling, a digital servo feedback encoder for absolute position detection over more than 4096 revolutions, and a plain shaft with seal. The unit has a centering diameter of 130 mm, a flange size of 140/150 mm, and a power output connection directed to side A via output connector. There is no integrated holding brake. Black coated housing provides resistance to environmental factors.

Technical Specifications

Energy Conversion
Converts Electrical Energy to Kinetic Energy

Housing
Durable Housing with Warning Signs and Symbols

Characteristic Speed
4000 Revolutions Per Minute

Continuous Current
30 Amperes

Peak Current
101.2 Amperes

Peak Speed
6000 Revolutions Per Minute

Required Cables
Power Cable and Motor Feedback Cable

External Coating
Prime Black Coat

Frequently Asked Questions

What cooling method is used in the MHD093B-058-PG0-AN motor?

The MHD093B-058-PG0-AN motor uses liquid cooling.

Does the MHD093B-058-PG0-AN motor include a holding brake?

The MHD093B-058-PG0-AN motor is built without a holding brake.

What shaft design does the MHD093B-058-PG0-AN motor have?

The MHD093B-058-PG0-AN motor features a plain shaft.

Where is the power connection on the MHD093B-058-PG0-AN motor?

The MHD093B-058-PG0-AN motor has the connection on side A.

What winding code is used in the MHD093B-058-PG0-AN motor?

The MHD093B-058-PG0-AN motor uses winding code 058.

Common Misspellings

MHD093B058PG0AN

MHD093B 058 PG0 AN

mhd093b-058-pg0-an

MHD93B-058-PG0-AN

Internal Product Review

The MHD093B-058-PG0-AN is praised for reliable operation in different configurations. It runs smoothly and integrates without difficulty. Users value its stable performance under ongoing use, noting its practicality and dependability for long-term operation without frequent intervention or complications.
