R911276121 (MHD112C-024-NP0-RN)

Name: R911276121 (MHD112C-024-NP0-RN)
Brand: Indramat Motors
SKU: MHD112C-024-NP0-RN
Price: 275.00 USD
Availability: InStock

MHD Synchronous Motors

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

6 Minutes 43 Seconds

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911276121 (MHD112C-024-NP0-RN) is a Bosch Rexroth MHD series servo motor equipped with digital servo feedback (HSF) and designed for use in environments that adhere to the operational specifications detailed in the product documentation. The unit features a key shaft with a sealing ring, a liquid-cooled housing for convection and surface cooling, and does not include a holding brake. Key technical parameters include a flange size of 192 mm, a centering diameter of 130 mm, and a continuous standstill torque of 38.0 Nm. The power connector is oriented to the right. Position detection is relative, and the motor winding code is 024.

Technical Specifications

Product Line
MHD

Usage
Servo and Main Drive Motors

Drive Controller Requirement
Yes

Accessories Requirement
Specified in Documentation

Software Requirement
Specified in Functional Description

Environmental Condition Requirement
Specified in Documentation

Improper Usage Consequences
Damage, Bodily Harm, Electric Shock

Servo Feedback
Digital

Shaft
With Key and Sealing Ring

Housing Design
For Natural Convection and Surface Cooling

Holding Brake
Not Included

Power Connector Position
Right

Mounting Type
Flange

Flange Size
192mm

Centering Diameter
130mm

Weight
45kg

Frequently Asked Questions

What mechanical interface is used for reliable torque transfer in the MHD112C-024-NP0-RN?

This motor includes a keyed shaft that supports secure mechanical coupling and precise torque alignment. A shaft seal protects against contamination and wear over time.

How does the encoder setup influence real-time control accuracy?

It uses digital servo feedback with HSF technology and relative position detection. This provides accurate motion feedback during operation but requires homing after power loss.

What thermal strategy is applied for extended duty applications?

A liquid-cooled housing enables stable temperature regulation even during prolonged operation. This ensures consistent performance under thermal load in dense machine environments.

Which connector layout helps streamline electrical installation?

The power connector is mounted to the right-hand side. This arrangement simplifies cable routing and minimizes stress in applications with constrained panel geometry.

What form factor ensures mounting compatibility with industrial assemblies?

A 130 mm centering diameter and 192 mm flange enable direct mounting into standardized mechanical frames. This supports easy alignment with gearboxes or load structures.

Common Misspellings

MHD112C024NP0RN

MHD112C 024 NP0 RN

mhd112c-024-np0-rn

Internal Product Review

The model MHD112C-024-NP0-RN is a Bosch Rexroth servo motor built with a right-mounted power connector for streamlined installation. It features HSF digital feedback, a keyed shaft, 192 mm flange, and 130 mm centering diameter. Its liquid cooling system ensures optimal thermal performance in continuous industrial operation.
