R911276733 (MHD112B-058-PG0-LN)

MHD Synchronous Motors

In Stock, Ships Today

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911276733 (MHD112B-058-PG0-LN) is a synchronous servo motor engineered for precise industrial motion control applications. This model features a plain shaft with shaft seal, liquid cooling, and a digital servo feedback encoder for absolute position detection exceeding 4096 revolutions. With a continuous torque at standstill of 28.0 Nm and capable of operating up to 4000 RPM (typical 3000 RPM), the motor has a winding inductivity of approximately 5.5 mH. The motor's structural dimensions include a flange size of 192 mm, centering diameter of 130 mm, and motor length designated as 'B'. It is constructed to support high radial loads, direct mounting of pinions or belt pulleys, and is supplied without a holding brake. The power connector is oriented to the left, and the total weight is approximately 34 kg. This unit complies with DIN 42948 requirements and is identified by winding code 058.

Technical Specifications

Product Type
Industrial Synchronous Motor

Design
Flange design according to DIN 42948

Encoder Type
Internal memory encoder

Operating Speed Range
Wide

Motor Type
Permanent magnet motor

Output Shaft
Supports high radial loads

Motor Speed
3000 revolutions per minute

Weight
34 kilograms

Winding Inductivity
5.5 millihenries.
