R911276830 (MHD112B-024-NG1-AN)

Name: R911276830 (MHD112B-024-NG1-AN)
Brand: Indramat Motors
SKU: MHD112B-024-NG1-AN
Price: 274.00 USD
Availability: InStock
Rating: 4.4 (10 reviews)

MHD Synchronous Motors

Rated 4.4 stars (10 total reviews)

Front Right

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

4 Minutes 1 Seconds

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The Bosch Rexroth synchronous servo motor MPN R911276830 (MHD112B-024-NG1-AN) features a 28.0 Nm continuous standstill torque, 192 mm flange size, and 130 mm centering diameter within a 112 frame size. The unit integrates a digital servo feedback (HSF) encoder for relative position detection and supports precise control. It operates with a peak current of 98.5 A, rated current of 4.9 A, up to a maximum speed of 4,000 rpm at a rated voltage of 461 V. The motor employs liquid cooling, includes a holding brake with 22.0 Nm torque, and maintains an IP65 protection rating for use in demanding environments. The plain shaft design includes a shaft seal, and the power connection is to side A via output connector. The device is compatible with worm gears 058 and planetary gear units like GTS, GTM, and GTP.

Technical Specifications

Product
MHD Synchronous Motors

Application
Automation Systems

Frame Size
112

Flange Size
192mm

Centering Diameter
130mm

Continuous Torque at Standstill
28.0Nm

Winding Code
024

Feedback
Integrated Digital Servo

Degree of Protection
IP 65

Cooling
Natural

Peak Current
98.5 Amp

Rated Current
4.9 Amp

Maximum Speed
4000rpm

Rated Voltage
461V

Material
Special Magnet

Design
Low Inertia Mass

Communication
Electronic

Frequently Asked Questions

Does the MHD112B-024-NG1-AN include a holding brake?

The MHD112B-024-NG1-AN includes a 22.0 Nm brake.

What cooling is used in the MHD112B-024-NG1-AN?

The MHD112B-024-NG1-AN uses liquid cooling.

What encoder is installed in the MHD112B-024-NG1-AN?

The MHD112B-024-NG1-AN uses a digital servo feedback (HSF) encoder.

What type of position detection does the MHD112B-024-NG1-AN support?

The MHD112B-024-NG1-AN supports relative position detection.

Where is the power connector of the MHD112B-024-NG1-AN?

The MHD112B-024-NG1-AN has its connector on side A.

Common Misspellings

MHD 112B 024 NG1 AN

MHD 112B-024-NG1-AN

MHD-112B-024-NG1-AN

MHD112B-O24-NG1-AN

MHD112B024NG1AN

MHDII2B-024-NGI-AN

MHD112B 024 NG1 AN

mhd112b-024-ng1-an

Internal Product Review

The MHD112B-024-NG1-AN is recognized for its consistent work capability and long-lasting structure. Operators appreciate the stable results it delivers across different uses. Its reliable construction ensures confidence during operation. Customers find it an efficient model that fits well into different systems, making it a practical option for everyday performance needs.
