R911278440 (MHD090B-035-NG1-UN)

Name: R911278440 (MHD090B-035-NG1-UN)
Brand: Indramat Motors
SKU: MHD090B-035-NG1-UN
Price: 980.00 USD
Availability: InStock
Rating: 4.1 (8 reviews)

MHD Synchronous Motors

Rated 4.1 stars (8 total reviews)

Front Right

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

3 Minutes 4 Seconds

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911278440 (MHD090B-035-NG1-UN) is a permanent magnet servo motor engineered with low inertial mass, utilizing specialized magnet materials. This model employs a brushless design with grease-lubricated bearings and features a closed, IP65-protected housing for operation in demanding environments. The motor supports liquid cooling and includes a holding brake with an 11.0 Nm torque rating. Key specifications include a 12.0 Nm continuous standstill torque, digital servo feedback (HSF) encoder for relative position detection, and a plain shaft with a shaft seal. The device has a centering diameter of 110 mm, a flange size of 140 mm compliant with DIN 42948, and a motor length designated as B. Its power connection is turnable within a 270° range and incorporates both power and feedback connectors. The winding code is 035.

Technical Specifications

Product Type
Permanent Magnet Motor

Operational Reliability
High

Maintenance
Maintenance-free

Design
Brushless with Grease Lubricated Bearings

Housing Protection Standard
IP 65

Motor Temperature Monitoring
Yes

Performance
High

Dynamics
High

Torque to Inertia Mass Ratio
Favorable

Electronic Commutation
Yes

Installation Positions
DIN 42948 Specifications for the Flange.

Frequently Asked Questions

Does the holding brake on the MHD090B-035-NG1-UN provide dynamic braking?

No, the holding brake is designed only for static holding when power is removed. It is not rated for motion braking or emergency stop functionality.

Why is a high-resolution digital feedback encoder useful in precision applications?

It enables fine position control down to arc-second resolution, minimizing error during motion. This is critical for synchronized multi-axis operations or micro-positioning.

What’s the practical effect of the 12.0 Nm continuous torque at standstill?

It ensures stable load holding during dwell periods without the need for additional external braking. This is especially valuable in vertical axis or clamping applications.

Can the MHD090B-035-NG1-UN be used in multi-axis automation systems?

Yes, its integration-ready encoder and standard flange dimensions support tight coupling with modular drive systems. That makes it suitable for gantries, pick-and-place arms, and robotic platforms.

Is the shaft seal sufficient for dusty or oily environments?

The integrated shaft seal helps protect the internal bearings and encoder from contaminant ingress. It increases reliability in machining, food packaging, or press automation setups.

Common Misspellings

MHD 090B-035-NG1-UN

MHD-090B-035-NG1-UN

MHD090B 035 NG1 UN

MHD090B-035-NGI-UN

MHD090B035NG1UN

MHDO9OB-O35-NG1-UN

mhd090b-035-ng1-un

MHD090B035NG1UN

MHD090B 035 NG1 UN

MHD90B-035-NG1-UN

Internal Product Review

The MHD090B‑035‑NG1‑UN is a synchronous servo motor by Bosch Rexroth Indramat. It delivers 12 Nm continuous torque at standstill, 11 Nm via its holding brake, and supports a 270° turnable connector layout for flexible cabling. Its sealed liquid‑cooled housing ensures maintenance‑free operation via lifetime lubricated bearings.
