R911279015 (MHD090B-058-NP1-UN)

Name: R911279015 (MHD090B-058-NP1-UN)
Brand: Indramat Motors
SKU: MHD090B-058-NP1-UN
Price: 389.00 USD
Availability: InStock
Rating: 4.7 (12 reviews)

MHD Synchronous Motors

Rated 4.7 stars (12 total reviews)

Front Right

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

6 Minutes 36 Seconds

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911279015 (MHD090B-058-NP1-UN) is a Rexroth synchronous servo motor with a maximum speed of 5000 RPM and an optimum operational speed of 4000 RPM. It delivers a peak torque of 43.5 Nm with a peak current of 79 A and provides a holding brake torque of 11.0 Nm. The motor uses a digital servo feedback encoder for position detection and features a keyed shaft with seal. Its IP65-rated housing supports convection cooling and employs F-class insulation as per DIN VDE 0530 Part 1. The device is suited for installation at altitudes up to 1000 meters and within a 0 to 40°C ambient temperature range. Key dimensions include a 140 mm flange, 110 mm centering diameter, and "B" length, with a total mass of approximately 14 kg.

Technical Specifications

Type
Synchronous Motor

Recommended Uses
Packaging Machines, Automation, Paper Industries

Motor Speed
4000 RPM

Max Speed
5000 RPM

Cooling Method
Convection

Operating Temperature Range
0 to 40 degrees Celsius

Storage Temperature Range
-20 to 80 degrees Celsius

Max Altitude for Installation and Operation
1000 meters above sea level

Protection Rating
IP65

Insulation Rating
F according to DIN VDE 0530 Part 1

Color
Prime Coat Black

Frame Size
90 (flange size 140 millimeters)

Frame Length
B (110 millimeters centering diameter)

Shaft Type
Keyed with sealing ring

Torque Constant at 20 Degrees Celsius
0.77 Nm/A

Winding Resistance
0.74 Ohms

Theoretical Peak Torque
43.5 Nm

Weight
14 kilograms.

Frequently Asked Questions

Does MHD090B-058-NP1-UN use a holding brake?

Yes, MHD090B-058-NP1-UN is equipped with a holding brake.

What brake torque does MHD090B-058-NP1-UN provide?

The holding brake of MHD090B-058-NP1-UN has 11 Nm torque.

What flange size is used in MHD090B-058-NP1-UN?

The MHD090B-058-NP1-UN has a flange size of 140 mm.

What centering diameter does MHD090B-058-NP1-UN support?

The centering diameter for MHD090B-058-NP1-UN is 110 mm.

What type of shaft seal is in MHD090B-058-NP1-UN?

The MHD090B-058-NP1-UN comes with a shaft seal.

Common Misspellings

MHD 090B-058-NP1-UN

MHD-090B-058-NP1-UN

MHD090B 058 NP1 UN

MHD090B-058-NPI-UN

MHD090B058NP1UN

MHDO9OB-O58-NP1-UN

mhd090b-058-np1-un

MHD090B058NP1UN

MHD090B 058 NP1 UN

MHD90B-058-NP1-UN

Internal Product Review

The MHD090B-058-NP1-UN is valued for dependable functionality across different working conditions. It maintains balanced operation and supports demanding workflows with ease. Users frequently highlight its consistent reliability, making it a strong fit for long-duration tasks. Its practical design ensures stability, which helps in building confidence in sustained, everyday use without performance concerns.
