R911279037 (MHD093B-058-PP0-BN)

MHD Synchronous Motors

Rated 4.9 stars (6 total reviews)

In Stock, Ships Today

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

3 Minutes 28 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth synchronous motor R911279037 (MHD093B-058-PP0-BN) is configured for high-precision automation applications and belongs to the MHD series. This size 093 motor in length B uses permanent magnets and features a keyed shaft with a shaft seal, digital servo feedback with an integrated absolute encoder (>4096 revolutions), and is designed without a holding brake. Equipped with four pole pairs, a continuous standstill torque of 17.5 Nm, and a characteristic speed of 4,000 min⁻¹, it supports liquid cooling and natural convection. The centering diameter is 130 mm, flange size is 140/150 mm, and maximum operating temperature is 40°C. The motor’s fully enclosed housing, meeting IP65 protection, is finished in RAL 9005 black and aligns with EMC regulations for installations up to 1,000 m above sea level.

Technical Specifications

Product Group
MHD

Size Code
093

Length Code
B

Operational Reliability
High

Performance Data
High

Motor Design
Fully Closed

Winding Code
058

Cooling
Liquid Cooling or Natural Convection

Use
Installation in Commercial Machinery

EMC Regulations Compliance
Yes

Pole Pairs
Four

Characteristic Speed
4,000 min-1

Coat
RAL 9005 prime black

Setup Height
Up to 1,000m above sea level
