The R911280028 (MHD093B-035-NG1-BN) is a Rexroth servo motor rated for high-overload operation with a permanent magnet design. It features a nominal speed of 2000 rpm and can operate up to 4500 rpm with a peak input current of 45.9 A. The motor incorporates a digital servo feedback (HSF) encoder for relative position detection and real-time signal transmission. The housing is IP65 rated, resistant to acids, alkalis, and hydraulic oils, and utilizes liquid cooling. Technical features include a plain shaft with seal, centering diameter of 130 mm, flange size 140/150 mm, motor length B, 093 frame size, and a holding brake providing 22.0 Nm of torque. Power connection is via an output connector at side B.

Technical Specifications

Product Type
Industrial Motor

Protection Class
IP65

Coat Resistance
Dilute Acids, Dilute Alkalis, Hydraulic Oils, Lyes

Recyclability
High Metal Content

Nominal Rotational Speed
2000 Revolutions Per Minute

Peak Input Current
45.9 Amperes

Maximum Speed
4500 Revolutions Per Minute

Rated Current
3.5 Milliamperes

Heat Regulation
Natural convection

Frequently Asked Questions

What is the cooling method of the MHD093B-035-NG1-BN?

The MHD093B-035-NG1-BN uses liquid cooling.

Does the MHD093B-035-NG1-BN feature a holding brake?

Yes, the MHD093B-035-NG1-BN includes a holding brake.

Where is the power connection for the MHD093B-035-NG1-BN located?

The MHD093B-035-NG1-BN has its power connector to side B.

What is the shaft design of the MHD093B-035-NG1-BN?

The MHD093B-035-NG1-BN features a plain shaft with seal.

Which winding code is assigned to the MHD093B-035-NG1-BN?

The winding code for the MHD093B-035-NG1-BN is 035.
