R911280217 (MHD115B-024-NG0-BN)

Name: R911280217 (MHD115B-024-NG0-BN)
Brand: Indramat Motors
SKU: MHD115B-024-NG0-BN
Price: 415.00 USD
Availability: InStock

MHD Synchronous Motors

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911280217 (MHD115B-024-NG0-BN) is a MHD synchronous servo motor from Bosch Rexroth engineered for integration in automation systems, machine tools, and similar applications. It features liquid cooling, a digital servo feedback (HSF) encoder with relative position detection, and a plain shaft design with sealing rings. The device provides 50.0 Nm continuous torque at standstill and operates at speeds up to 4,000 rpm. Specifications include a motor length B, centering diameter of 180 mm, flange size of 192 mm, and motor size 115. The shaft is plain and sealed, with the power connection directed to side B via an output connector. The enclosure is rated IP 65, suitable for operation at ambient temperatures up to 40°C, 95% humidity, and 1,000 m altitude.

Technical Specifications

Product
Bosch Rexroth MHD Synchronous Motors

Cooling Type
Surface Cooling

Encoder Type
Integrated Optical Encoder

Data Memory
Yes

Shaft Type
Plain Shaft with Shaft Sealing Rings

Maximum Speed
4,000 RPM

Color
Black Prime Coat in a/w RAL 9005

Design
Closed Design

Protection Class
IP 65

Maximum Ambient Temperature
40°C

Relative Humidity
95%

Maximum Installation Height
1000m above mean sea level

Frequently Asked Questions

How does liquid cooling improve the servo motor’s performance?

The liquid cooling removes excess heat allowing sustained high torque without thermal overload. The thermal stability enhances precision and prevents performance drift during long duty cycles.

What benefit does a plain shaft with seal provide in industrial use?

The plain shaft ensures precise coupling alignment with low vibration levels. The seal prevents contamination entry and protects the bearing system in dusty or wet conditions.

Why is digital servo feedback critical in precision automation?

The digital servo feedback delivers real time position and speed data to the controller. The accuracy of this feedback minimizes positioning errors and enables synchronized multi axis control.

How does continuous torque at standstill affect motion control systems?

The ability to maintain rated torque at zero speed enables stable holding of loads. The feature is essential for robotics presses and tension control systems requiring precise load retention.

How should the output connector on side B be oriented during wiring?

The connector should be oriented to minimize cable strain and maintain bending radius limits. The layout must ensure electromagnetic compatibility with nearby signal lines.

Common Misspellings

MHD115B024NG0BN

MHD115B 024 NG0 BN

mhd115b-024-ng0-bn

Internal Product Review

The Bosch Rexroth Indramat MHD115B-024-NG0-BN servo motor offers liquid-cooled housing, plain shaft and digital servo feedback (HSF) with relative detection capability. Producing 50.0 Nm torque through a side-B connector it ensures balanced motion control in robotic lifting arms, textile conveyors and automated production modules requiring sustained torque reliability.
