R911281018 (MHD115B-024-PG1-BN)

MHD Synchronous Motors

In Stock, Ships 2-3 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911281018 (MHD115B-024-PG1-BN) is a Bosch Rexroth synchronous servo motor from the MHD series designed for precision automation applications, particularly in machine tools. It provides a nominal speed of 4000 min⁻¹ and a continuous standstill torque of 50.0 Nm. The motor features a 192 mm flange, 180 mm centering diameter, plain cylindrical shaft with a 420 mm length conforming to DIN 748 Part 3, and is equipped with a radial shaft sealing ring. It supports liquid cooling, has a holding brake with 70.0 Nm torque, and integrates digital servo feedback for absolute position detection over more than 4096 revolutions. The electrical power connection is via side B with a standardized output connector. Compatibility with GTS, GTP, or GTM planetary gear series is provided. The ground wire must remain permanently connected, and the housing becomes hot during operation.

Technical Specifications

Product Type
Synchronous Motor

Primary Usage
Machine Tools

Risk of Held Under Motor Operation
Yes

Characteristic Motor Speed
4000min-1

Flange Size
192mm

Encoder System
Included

Cooling System
Liquid and Natural Convection

Radial Shaft Sealing Ring
Present

Cylindrical Shaft End
As per DIN 748, Part 3

Axial Force
0.26 times Radial Force

Length
420mm

Electric Connections
Standardized

Location of Dispatch
Global

Frequently Asked Questions

Common Misspellings

Internal Product Review

The MHD115B-024-PG1-BN is a reliable motor with excellent thermal management. However, its liquid-cooled design can complicate setups, especially for first-time users
