R911282232 (MHD112B-058-PP0-RN)

Name: R911282232 (MHD112B-058-PP0-RN)
Brand: Indramat Motors
SKU: MHD112B-058-PP0-RN
Price: 579.00 USD
Availability: InStock

MHD Synchronous Motors

Front Left

In-Stock, Ships 1-2 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

4 Minutes 57 Seconds

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911282232 (MHD112B-058-PP0-RN) is a Rexroth Indramat servo motor characterized by a keyed shaft with shaft seal, liquid-cooled housing, and a digital servo feedback encoder with integrated absolute position detection over more than 4096 revolutions. The unit achieves continuous torque at standstill of 28.0 Nm and rated output torque of 42 Nm at 4000 RPM with approximately 61 A rated current. The motor has a size 112 frame, length B, 130 mm centering diameter, and 192 mm flange size. Shaft construction follows DIN 6885-1, and the power connection is a right-facing power connector. This model is specified without a holding brake and uses winding code 058.

Technical Specifications

Noise Level
Low

Bearing Type
Special Ball Bearings

Motor Type
Brushless with electronic commutation

Torque Output
High over broad speed range

Load Capacity
High

Rated Current
61 amperes

Revolution Speed
4000 revolutions per minute

Output Torque
42 newton meters

Design
Compact

Output Shaft
Key according to DIN 6885-1

Temperature Regulation System
Natural convection.

Frequently Asked Questions

How is shaft protection ensured in demanding industrial environments?

The plain shaft includes an integrated shaft seal to block contaminants. This enhances long-term reliability in dust- or fluid-exposed applications.

Can the MHD112B-058-PP0-RN deliver constant torque when the rotor is stationary?

It provides 28.0 Nm of continuous torque at standstill. This supports load-holding in indexing or zero-speed dwell operations.

What feedback mechanism supports position tracking in automated systems?

The motor uses digital servo feedback with an integrated encoder. This enables accurate and responsive closed-loop motion control.

How does the motor maintain thermal performance under sustained load?

Its liquid-cooled housing regulates heat during high-duty operation. This ensures stable performance without thermal derating.

Will the mounting interface align with standard industrial servo platforms?

It features a 192 mm flange size for standardized mounting compatibility. This simplifies integration into modular machine assemblies.

Common Misspellings

MHD112B058PP0RN

MHD112B 058 PP0 RN

mhd112b-058-pp0-rn

Internal Product Review

The MHD112B-058-PP0-RN by Bosch Rexroth is a servo motor designed with a 192 mm flange for secure industrial mounting. It offers 28.0 Nm torque at standstill, a sealed shaft for durability, and efficient liquid cooling. The motor's integrated digital servo feedback encoder ensures precise motion tracking and reliable position control.
