The R911282479 (MHD090B-035-PP1-UN) is a Bosch Rexroth Indramat synchronous servo motor equipped with liquid-cooled housing for efficient thermal management. It features a 140 mm flange size, 110 mm centering diameter, and a 'B' motor length, delivering 12.0 Nm continuous torque at standstill. The motor supports a keyed shaft with a shaft seal per DIN 6885-1, includes a 22 Nm holding brake for secure positioning when de-energized, and utilizes digital servo feedback with a multiturn absolute encoder for position detection exceeding 4096 revolutions. The power and feedback connectors are turnable within a 270-degree range.

Technical Specifications

Motor Type
MHD Synchronous Motors

Motor Frame Size
140mm Flange Size

Centering Diameter
110mm

Motor Frame Length
12Nm

Winding Code
35

Servo Feedback
Digital

Shaft Sealing
With sealing ring

Keyway
According to DIN 6885-1

Holding Brake Capacity
22Nm

Housing Type
Liquid cooling allowed

Shipping Availability
Global Delivery

Product Type
Industrial Drive&Rigidity Control&Motion Control.
