The R911283054 (MHD093C-058-PG0-AN) is a brushless, permanent-magnet excited servo motor designed for continuous start-stop operation with high frequency. It operates at a standard speed of 2000 RPM and can reach up to 6000 RPM, with a rated input current of 6.9 A, a maximum input current of 127 A, a rated voltage of 168 V, and a frequency of 133 Hz. This unit features a plain output shaft with a keyway to DIN 6885-1, is housed in a liquid-cooled casing, and weighs 23.5 kg. It is equipped with digital servo feedback with absolute position detection and integrated encoder, has a centering diameter of 130 mm, a flange size of 140/150 mm, and delivers a continuous standstill torque of 23.0 Nm. Power connects via side A with an output connector. The motor does not include a holding brake and is identified with winding code 058.

Technical Specifications

Type
Permanent-Magnet Excited Motor

Energy Conversion
Electrical to Kinetic

Design
Brushless

Operation Noise Level
Low

Recyclable
Yes

Nominal Speed
2000 Revolutions Per Minute

Peak Speed
6000 Revolutions Per Minute

Rated Input Current
6.9 Amperes

Rated Voltage
168 Amperes

Rated Frequency
133 Hertz

Torque Constant at 20 degrees Celsius
0.91 Newton Meters Per Ampere

Voltage Constant
82.7 Volts Per Minute

Pole Pairs
4

Weight
23.5 Kilograms

Winding Inductivity
2.6 Milihenries

Output Shaft Design
Keyway according to DIN 6885-1.

Frequently Asked Questions

Does the MHD093C-058-PG0-AN benefit from having its output connector on side A?

Yes, the side A output connector allows for easier cable routing and accessibility. It simplifies installation and reduces interference with nearby machine parts.

How does the liquid cooling system in the MHD093C-058-PG0-AN enhance operational efficiency?

It ensures efficient heat dissipation during prolonged operation. This helps the motor maintain stable torque and prevents thermal overload.

Do the Winding Code 058 specifications in the MHD093C-058-PG0-AN affect its dynamic response?

Yes, the 058 winding code is optimized for rapid acceleration and deceleration. It supports fast and precise motion control in automation systems.

How does the reinforced plain shaft with a shaft seal improve the reliability of the MHD093C-058-PG0-AN?

The seal prevents entry of contaminants like oil and dust into the shaft area. This feature enhances bearing life and ensures smooth, long-term performance.

Does the Absolute Position Detection system in the MHD093C-058-PG0-AN improve servo accuracy?

Yes, with 4096 revolutions of detection, it delivers ultra-fine feedback resolution. This ensures high precision in positioning and multi-axis synchronization.

Common Misspellings

MHD093C058PG0AN

MHD093C 058 PG0 AN

mhd093c-058-pg0-an

MHD93C-058-PG0-AN

Internal Product Review

The Bosch Rexroth Indramat MHD093C-058-PG0-AN Servo Motor delivers precise motion control with a continuous torque of 23.0 Nm and liquid-cooled housing for efficient thermal management. Its digital servo feedback with absolute position detection ensures accurate operations. Widely used in CNC machining, robotics, and automated assembly, it supports demanding industrial automation systems.
