R911283309 (MHD090B-058-PG1-UN)

Name: R911283309 (MHD090B-058-PG1-UN)
Brand: Indramat Motors
SKU: MHD090B-058-PG1-UN
Price: 239.00 USD
Availability: InStock
Rating: 4.1 (8 reviews)

MHD Synchronous Motors

Rated 4.1 stars (8 total reviews)

Front Right

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

4 Minutes 45 Seconds

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The Bosch Rexroth R911283309 (MHD090B-058-PG1-UN) is a synchronous servo motor with a permanent magnet core and a 4-pole electrical design. It supports both naturally cooled and surface-cooled configurations, with rated torque up to 13.4 Nm and power output up to 7.0 kW, depending on the cooling method. The motor operates at a rated speed of 4,000 RPM and 267 Hz. Key features include a plain shaft with shaft seal, absolute position detection (over 4096 revolutions) via a digital multiturn encoder, and an 11.0 Nm holding brake. The housing features a liquid cooling system and a 140 mm flange size, 110 mm centering diameter, and 14 kg weight. Power and feedback connections are provided by turnable connectors within a 270° range.

Technical Specifications

Product Range
MHD Synchronous Motors

Design
Maintenance-Free Brushless

Core
Permanent Magnet

Cooling Options
Naturally Cooled; Surface Cooled

Rated Torque (Naturally Cooled 60K)
4.2Nm

Rated Performance (Naturally Cooled 60K)
2.1kW

Rated Torque (Naturally Cooled 100K)
8.9Nm

Rated Performance (Naturally Cooled 100K)
4.9kW

Rated Torque (Surface Cooled)
13.4Nm

Rated Performance (Surface Cooled)
7.0kW

Nominal Speed
4,000 RPM

Rated Frequency
267 Hz

Number of Poles
4 poles

Weight
14 kg

Encoder Type
High Accuracy Multiturn Absolute Encoder

Holding Brake
11.0Nm

Frequently Asked Questions

What encoder is used in MHD090B-058-PG1-UN?

The MHD090B-058-PG1-UN features an integrated encoder.

What detection method does MHD090B-058-PG1-UN employ?

MHD090B-058-PG1-UN uses absolute detection with >4096 revolutions.

What type of shaft is on MHD090B-058-PG1-UN?

The MHD090B-058-PG1-UN is built with a plain shaft.

What is the motor length of MHD090B-058-PG1-UN?

The motor length code for MHD090B-058-PG1-UN is “B.”

What connection type does MHD090B-058-PG1-UN use?

MHD090B-058-PG1-UN includes both power and feedback connectors.

Common Misspellings

MHD 090B 058 PG1 UN

MHD 090B-058-PG1-UN

MHD-090B-058-PG1-UN

MHD090B-058-PGI-UN

MHD090B058PG1UN

MHDO9OB-O58-PG1-UN

MHD090B 058 PG1 UN

mhd090b-058-pg1-un

MHD90B-058-PG1-UN

Internal Product Review

The MHD090B-058-PG1-UN stands out for its reliable function and stable control during extended operation. It adapts well to system requirements, providing dependable support for diverse processes. Users note its predictable behavior and low-maintenance nature. This makes it a dependable choice for settings where long-lasting performance and steady operation are critical factors for success.
