R911283437 (MHD112B-048-NP1-BN)

Name: R911283437 (MHD112B-048-NP1-BN)
Brand: Indramat Motors
SKU: MHD112B-048-NP1-BN
Price: 996.00 USD
Availability: InStock
Rating: 4.8 (5 reviews)

MHD Synchronous Motors

Rated 4.8 stars (5 total reviews)

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The Bosch Rexroth MPN R911283437 (MHD112B-048-NP1-BN) is a synchronous servo motor equipped with a B-side power output connector and a keyed shaft in accordance with DIN 6885-1, featuring a shaft seal. Designed with insulation class F per DIN VDE 0530, it operates at a rated speed of 2800 min-1 (187 Hz) with a voltage constant of 80 V per 1000 min-1. The unit has a holding brake rated at 22.0 Nm, integrates liquid cooling, and utilizes digital servo feedback for position detection. Its mechanical dimensions include a flange size of 192 mm, centering diameter of 130 mm, and a length code 'B'. The motor's low inertia is attributable to its specific magnet material choice, and a brushless configuration minimizes heat dissipation. Installation should ensure correct shaft alignment and secure power supply connection. The integrated brake is managed directly by the drive controller.

Technical Specifications

Power Connection Location
B side

Shaft Design
Keyway, DIN 6885-1 specifications

Shaft Feature
Shaft sealing ring

Holding Brake
22Nm

Insulation
Class F, DIN VDE 0530 specifications

Rated Frequency
187Hz

Rated Speed
2,800min-1

Winding Inductivity
3.1mH

Winding Resistance
0.22 Ohm at 20degC

Design
Brushless, maintenance-free operation

Materials
Special magnet materials, low inertia

Torque Constant
0.88Nm/A at20degC

Software Guidelines
Source code not to be changed

Motor Brake Safety
Not sufficient for personal safety

Holding Brake Specs
3.6 x 10-4 moment of inertia, 1.1kg

Voltage Constant
80V/1,000min-1

Length
375mm

Frequently Asked Questions

Does the MHD112B-048-NP1-BN include a brake?

The MHD112B-048-NP1-BN includes a 22.0 Nm brake.

What type of shaft is in the MHD112B-048-NP1-BN?

The MHD112B-048-NP1-BN has a keyed shaft with seal.

What encoder is used in the MHD112B-048-NP1-BN?

The MHD112B-048-NP1-BN uses a digital servo feedback (HSF).

What type of position detection is supported by the MHD112B-048-NP1-BN?

The MHD112B-048-NP1-BN supports relative detection.

Where is the connector on the MHD112B-048-NP1-BN?

The MHD112B-048-NP1-BN has its connector on side B.

Common Misspellings

MHD 112B-048-NP1-BN

MHD-112B-048-NP1-BN

MHD112B 048 NP1 BN

MHD112B-O48-NP1-BN

MHD112B048NP1BN

MHDII2B-048-NPI-BN

mhd112b-048-np1-bn

MHD112B048NP1BN

Internal Product Review

The MHD112B-048-NP1-BN has earned strong reviews from operators who value reliability. Customers consistently report smooth performance during usage. Its ability to maintain dependable outcomes builds trust among users. Many highlight that it provides reassurance during demanding operations. This model is a favored choice for those seeking efficiency combined with consistent operation.
