R911283749 (MHD115B-024-PG1-AN)
MHD Synchronous Motors
Technical Specifications
Product Type
Synchronous Servo Motor
Temperature Monitoring
Yes, with thermal sensors
System Accuracy
±0.5 angular minutes
Data Storage Feature
Yes
Chemical Resistance
Yes, against diluted acids and lyes
Shaft
Plain shaft with a shaft sealing ring.
Frequently Asked Questions
How does liquid cooling improve the motor’s operational stability?
The cooling system maintains consistent temperature during high duty cycles. The result is extended service life and uninterrupted torque output.
Why is the holding brake critical for machine safety and accuracy?
The brake holds the shaft firmly when power is off preventing unwanted movement. The feature ensures stable positioning in vertical and high precision applications.
How does digital servo feedback enhance performance accuracy?
The feedback encoder provides real time data to the control system. The continuous feedback loop ensures smooth and accurate motion control.
What advantage does absolute position detection provide?
The system retains position information even after shutdown. The function removes the need for recalibration on startup increasing productivity.
How does the plain shaft design support flexible installation?
The shaft connects directly to mechanical loads without extra couplers. The design simplifies setup and minimizes mechanical play.
Common Misspellings
MHD115B024PG1AN
MHD115B 024 PG1 AN
mhd115b-024-pg1-an
Internal Product Review
The Bosch Rexroth Indramat MHD115B-024-PG1-AN servo motor has a liquid cooling with 70 Nm holding brake torque and 50 Nm continuous stall torque. It suits automated storage systems and injection molding where accurate positioning and quick torque response with side-A connector orientation enhance stability and safety in extended multi axis manufacturing setups.
