R911284637 (MHD112B-048-PP0-AN)

Name: R911284637 (MHD112B-048-PP0-AN)
Brand: Indramat Motors
SKU: MHD112B-048-PP0-AN
Price: 333.00 USD
Availability: InStock
Rating: 4.5 (7 reviews)

MHD Synchronous Motors

Rated 4.5 stars (7 total reviews)

Front Left

In-Stock, Ships 1-2 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

4 Minutes 5 Seconds

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The MPN R911284637 (MHD112B-048-PP0-AN) is a synchronous servo motor within the MHD series, featuring a 192 mm flange, 130 mm centering diameter, and a B-frame length. It is equipped with winding code 048 and delivers a continuous standstill torque of 28.0 Nm. The motor employs liquid cooling and is constructed with a keyed output shaft per DIN 6885-1, including a shaft seal. The power connector is output to side A. Position feedback is provided by a digital multi-turn absolute encoder. The motor runs at a rated speed of 2800 min⁻¹ with a theoretical maximum torque of 102.0 Nm and a moment of inertia of 192.0×10⁻⁴ kg·m².

Technical Specifications

Flange Size
192mm

Centering Diameter
130mm

Motor Frame Length
28Nm

Winding Code
48

Holding Brakes
No

Housing Type
Liquid Cooling

Power Connector Direction
Side A

Output Shaft
With Sealing Ring

Encoder Type
Digital with Integrated Multi-Turn Feedback

Rated Speed
2800 min-1

Moment of Inertia
192.0x10-4

Theoretical Maximum Torque
102.0 NM

Available for Global Shipping
Yes

Frequently Asked Questions

What shaft design does the MHD112B-048-PP0-AN motor have?

The MHD112B-048-PP0-AN motor features a keyed shaft.

Does the MHD112B-048-PP0-AN motor have a holding brake?

No, the MHD112B-048-PP0-AN motor comes without a holding brake.

What encoder is included in the MHD112B-048-PP0-AN motor?

The MHD112B-048-PP0-AN uses a digital servo feedback encoder with integration.

What is the torque rating of the MHD112B-048-PP0-AN motor at standstill?

The MHD112B-048-PP0-AN provides 28.0 Nm continuous torque at standstill.

Which cooling system does the MHD112B-048-PP0-AN motor use?

The MHD112B-048-PP0-AN motor is liquid cooled.
