R911284826 (MHD093C-035-PP1-AN)

Name: R911284826 (MHD093C-035-PP1-AN)
Brand: Indramat Motors
SKU: MHD093C-035-PP1-AN
Price: 515.00 USD
Availability: InStock
Rating: 4.6 (13 reviews)

MHD Synchronous Motors

Rated 4.6 stars (13 total reviews)

Front Right

In-Stock, Ships 1-2 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

6 Minutes 25 Seconds

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911284826 (MHD093C-035-PP1-AN) is a synchronous servo motor featuring a keyed shaft and shaft seal, designed for use in automation systems requiring high repeat intervals and frequent start-stop cycles. The unit includes a digital servo feedback system with an integrated multiturn absolute encoder, providing position detection accuracy of +/- 0.5 angular minutes over more than 4096 revolutions. The motor is equipped with a 22 Nm holding brake, offers a continuous standstill torque of 23 Nm at 18.5 A under natural convection cooling, and features liquid cooling. Its flange measures 140/150 mm with a centering diameter of 130 mm. The winding has an inductivity of 3.2 mH and a resistance of 0.79 Ohms at 20°C. The motor must be properly grounded and is not compatible with radio, remote control, or high-frequency devices.

View Datasheet

Technical Specifications

Start Mode
Data Memory

Operation Type
Continuous Start-stop

Heat Dissipation
Between Exterior Wall and Stator Windings

Holding Brake
22Nm

Flange Size
140mm or 150mm

Centering Diameter
130mm

Continuous Torque
23Nm

Continuous Current
18.5A

Cooling Mode
Natural Convection

Encoder System
Integrated

Winding Inductivity
3.2mH

Winding Resistance
0.79 Ohms at 20°C

Torque Constant
1.39Nm/A

Voltage Constant
126.4V/1,000min-1 at 20°C

Shaft Design
DIN 6885-1 Keyway Shaft

Encoder Accuracy
+/-0.5 Angular Minutes

Frequently Asked Questions

What brake torque is supported in MHD093C-035-PP1-AN?

The MHD093C-035-PP1-AN supports a 22.0 Nm holding brake torque.

What encoder type is in MHD093C-035-PP1-AN?

The MHD093C-035-PP1-AN uses a digital servo feedback encoder with absolute detection.

What motor size applies to MHD093C-035-PP1-AN?

The MHD093C-035-PP1-AN is part of motor size 093.

Which shaft design is provided in MHD093C-035-PP1-AN?

The MHD093C-035-PP1-AN is manufactured with a keyed shaft.

What power connector direction is on MHD093C-035-PP1-AN?

The MHD093C-035-PP1-AN has its connector facing side A.

Common Misspellings

MHD 093C 035 PP1 AN

MHD 093C-035-PP1-AN

MHD-093C-035-PP1-AN

MHD093C-035-PPI-AN

MHD093C035PP1AN

MHDO93C-O35-PP1-AN

MHD093C 035 PP1 AN

mhd093c-035-pp1-an

MHD93C-035-PP1-AN

Internal Product Review

The MHD093C-035-PP1-AN earns strong feedback for its consistent behavior and dependable function. Customers describe it as straightforward to integrate and effective in maintaining operations. It delivers reliable results across diverse needs. This motor continues to be valued as a dependable solution, providing trusted service over time for many working environments.
