R911285062 (MHD112C-024-NP0-AN)

Name: R911285062 (MHD112C-024-NP0-AN)
Brand: Indramat Motors
SKU: MHD112C-024-NP0-AN
Price: 691.00 USD
Availability: InStock

MHD Synchronous Motors

Front Left

In-Stock, Ships 1-2 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

3 Minutes 23 Seconds

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911285062 (MHD112C-024-NP0-AN) is a Bosch Rexroth synchronous servo motor intended for integration into automated industrial systems such as machine tools, packaging, and paper machinery. The unit is equipped with a digital servo feedback encoder for relative position detection and utilizes a keyed shaft with a shaft seal. Flange mounting is supported with a 192 mm flange size and 130 mm centering diameter. Key performance parameters include a rated speed of 2500 RPM, maximum speed of 4000 RPM, and a characteristic speed of 2000 RPM. At standstill, the continuous torque and current values are 38 Nm and 26.6 A with natural convection, and 57 Nm and 39.9 A with surface cooling. Operation is specified for ambient temperatures between 0 and 45°C and up to 1000 m elevation. The servo motor features an IP65 housing, side A power output connector, and is supplied without a holding brake. Winding code is 024, and motor size is 112 with motor length C.

Technical Specifications

Maintenance
Maintenance-free

Cooling Type
Natural Convection or Surface Cooling

Characteristic Speed
2000 RPM

Continuous Torque at Standstill (Natural Convection)
38 Nm

Continuous Current at Standstill (Natural Convection)
26.6 Amps

Continuous Torque at Standstill (Surface Cooling)
57 Nm

Continuous Current at Standstill (Surface Cooling)
39.9 Amps

Rated Motor Speed
2500 RPM

Maximum Motor Speed
4000 RPM

Ambient Temperature
0 to 45 degrees Celsius

Maximum Setup Height
1000 meters

Housing Rating
IP65

Flange Size
192 millimeters

Centering Diameter
130 millimeters

Power Connector Location
Side A

Feedback
Digital Servo Feedback

Motor Shaft Includes
Key and sealing ring

Holding Brake
Not included but available to orde

Frequently Asked Questions

What are the mounting dimensions and torque performance at standstill?

The motor has a 130 mm centering diameter and a 192 mm flange. It delivers 38.0 Nm of continuous torque at standstill for heavy-duty industrial applications.

What is the thermal management method used in the MHD112C-024-NP0-AN?

This motor uses a liquid-cooled housing, which supports consistent heat dissipation under sustained load, ensuring stable performance in demanding environments.

Which encoder type is integrated in this motor and how is position monitored?

It features a digital servo feedback encoder (HSF) with relative position detection, supporting closed-loop control but requiring homing after power loss.

What are the shaft specifications and protection features?

A keyed shaft with an integrated shaft seal is included, offering secure torque transmission and protection against particle or fluid ingress.

How is this motor electrically integrated into machine systems?

It uses an output connector located on side A for power delivery, allowing straightforward cabling in left-side oriented control panels.

Common Misspellings

MHD112C024NP0AN

MHD112C 024 NP0 AN

mhd112c-024-np0-an

Internal Product Review

The MHD112C-024-NP0-AN is a synchronous servo motor equipped with a 130 mm centering diameter. It features liquid cooling, HSF digital feedback, a keyed shaft with seal, and a 192 mm flange for stable mounting. It is fully compatible with Bosch Rexroth HDS series drive controllers for seamless integration.
